Specifications
1.Yuchai marine engine adopting the technology of FEV,Germany;2.Chinese marine eng
YC6B Technical parameter
Engine Feature
1. This series diesel engine is developed by adopting the technology of FEV, Germany;
2. Cylinder block and cylinder head are made of alloy cast iron with high strength; crankshaft is made in a single piece; sliding bearing. Engine is compact in design, light on weight and with high reliability; overhaul life is more than 10,000 hours;
3. FEV port shrink combustion chamber technology, AD type high-pressure fuel pump and low-inertia & small aperture injector contribute to more intense combustion and lower fuel consumption. Oil consumption is reduced by more than 50% compared with products of the same power at home by adopting Yuchai* s special piston ring sealing technology and valve oil seal technology;
4. It is used as the ideal main machine for powering small-sized marines and fishery vessels and as the auxiliary machine for
5 40-64kW GEN-SETS.
Model |
YC6108ZLCA |
YC6B150C |
YC6B165L-C20 |
YC6B165C |
Type |
Vertical, in-line, water-cooled, four stroke |
|||
Intake way |
Inter-cooled & Turbo-charging |
|||
No. of cylinders X Bore X Stroke(mm) |
6×108×125 |
|||
Displacement (L) |
6.871 |
|||
Compression ratio |
17.5:1 |
|||
Continuous power /speed(kW(Ps)/r/min) |
90(123)/1500 |
110(150) /1800 |
120(165) /1800 |
120(165) /2300 |
One-hour power/speed(kW(Ps)/r/min) |
99(135)/1548 |
121(165) /1858 |
132(180) /1858 |
132(180) /2374 |
Min. specific fuel consumption(g/kW·h) |
≤198 |
|||
Specific oil consumption (g/kW·h) |
≤0.8 |
|||
Crankshaft rotation direction (seen from power output end) |
counterclockwise |
|||
Net weight (kg) |
750 |
|||
Overall dimensions (LxWxH) (mm) |
1420×810×1020 |
|||
Matched reduction gearbox |
HC65,120C |
|||
Certificaate |
ZC,ZY,CCS |
|||
Production Process
Factory & Global Service Network & Call center
Workshop
Certificate
