65 Inch LED Touch Board

Name: 65 Inch LED Touch Board
Brand: USER
SKU: 103449545
Availability: InStock

US$ 2,000 - 9,000 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

USER

Model Number:

US-T6501PC

Shenzhen USER Special Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name USER

Model Number US-T6501PC

Type TFT

Application Indoor

Panel Size 65inch

Max Resolution 1920*1080

Viewing Angle 178°/178°

Pixel Pitch 0.53*0.53

Color 16.7M

Contrast Ratio 16:9

Brightness 500

Response Time 5ms

Input Voltage 230W

65 inch LED Touch Board

Specifications
Model No.					US-TH6502WP
Panel size					65" TFT-LCD
Display area(mm)/mode					1508.0 x 878.0(mm 16:9
Maximum resolution					1920×1080
Display color					16.7M
Pixel Pitch(mm)					0.744(H)×0.744(V)
Brightness (nits)					500cd/
Contrast					5000:1
Visual angle					178°/178°
Response time					8ms
Horizontal frequency					50-70KHZ
Vertical frequency					56-75KHZ
Life(hrs)					>60,000(hrs)
Touch Panel
Specification					Infrared touch
Positioning accuracy					±2mms
Transmittance					≥92%
Hardness					7H
Click manner					double point/mult-point(optional)
Response time					10ms
Output Resolution					8192*8192
Life time					Single point of more than 600 million times
Input and output
VGA input					2
CVBS input					2
YPbPr input					1
TV					1
HDMI					4
USB2.0					6
LAN					1
PC Audio					1
Audio(L/R) input					1
Audio(L/R) output					1
Speaker					2×10W(8 ohm)
Video
Color system					PAL/NTSC/SECAM
Compatible HDMI input/DVI					480P,576P,720P,1080I,1080P
3D Comb filter					Yes
Video reduction noise					Yes
OSD display( screen menu display)
Menu language					Chinese/English
Computer
Main chipset					Intel H61
CPU					Intel I3-2100 3.1G
System bus frequency					800/1066/1333 MHz
Graphics card					Integrated
Audio card					Integrated AC97
Network card					Integrated 10/100/1000M adaptive
Memory					2G DDRIII (max 4G)
Hard Disk					320G SATA
WIFI					Optional
Bluetooth					Optional
Operation system					Windows 7
Power
Power supply					AC100V~240V,50/60Hz
Maximum power consumption					400W
Standby power consumption					3W
Temperature
Working temperature					0°C~50°C
Storage temperature					-10°C~60°C
Working humidity					20%~80%
Storage humidity					5%~95%
Appearance
Cabinet color/appearance					White, black, customized
Cabinet material					SPCC/Aluminum/Customized
Installation					Floor-standing
