Samsung screen 55" LCD video wall with LED Backlight

FOB Price

Negotiable / Piece

4 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

55" LCD Video Wall
Narrow bezel 5.3mm,brightness 700nits
Contrast 4000:1, rich interfaces
other size optional
LED backlight

55" LCD video wall with super narrow bezel 5.3mm

Specifications
Model No.			US-LTI550HN01
Panel size			55" DID LCD screen(with narrow bezel 5.3mm,with LED Backlight)
Aspect Ratio			16:9
Resolution			1920x1080
Color			8Bit,16.7M
Brightness (nits)			700cd/m2
Contrast			4000:1
Visual angle (H/V)			178°
Response time			<=6ms
Life(hrs)			>60,000(hrs)
Input and output
Composite Video Input/(AV)			3(3xBNC)
YUV/YPbPR			1(BNC×3)
S-(YC)			1(BNC×2)
D-15 RGB Input(VGA)			1
HDMI			1
DVI			1
AUDIO INPUT			1
Composite Video Output			2(BNC×2)
Split Screen			Support Picture in Picture(PIP/POP/PAP)
Power
Power supply			AC100V~240V
Maximum power consumption			250W
Standby power consumption			<=3W
Temperature
Working temperature			0°C~50°C
Working humidity			20%-80%
Appearance
Product dimension			1215.3mm(H) × 686.1mm(V)
Acessory
Cable			Can supply different kinds of cable
Video Wall Controller(Built-in each screen)
Model No.	US-P816A
Input	CVBS	3BNC inputs, support PAL/NTSC all formats, 2BNC loop outputs
	VGA	1*D15 port, support SVGA/XGA/WXGA
	YPbPr/YCbCr	1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
	Y/C	2*BNC inputs, support PAL/NTSC all formats
Output	LVDS	Support signal or double LVDS output, and WUXGA (1920*1080) display
Operate mode	Panel key operation(needs customization)
	Standard RS232 port( provide free control software)
	Infrared Remote Control Operation
Engineering software	Customized
Working temperature	0~70 °C
working humidity	5~95 %RH
AC voltage power supply	100-240V/50, 60Hz
power consumption	Max 300W,according to different screen models
Dimension	338×295×60(mm)
Weight	About 3.5KG
