42" DID Video Wall Bezel 27mm

Specifications

42" DID Video Wall
narrow bezel 27mm,brightness 600nits
Widely used/OEM
good quality, moderate price
good service,LG panel

42" DID Video Wall with bezel 27mm



Model No.					US-LC420WUD
Panel Size					42" LG S-PVA Screen(with narrow bezel 27mm)
Aspect Ratio					16:9
Max Resolution Support					1920x1080
Color					8Bit,16.7M
Brightness (nits)					600cd/m2
Contrast					1000:1
Visual Angle (H/V)					178°
Response Time					<=6ms
Life(hrs)					>60,000(hrs)
Input and output
DVI					1
HDMI					1
D-15 RGB Input(VGA)					1
YUV/YPbPR					1(3xBNC)
S-video					1(2xBNC)
Composite Video Input/(AV)					3(3xBNC)
Composite Video Output					2(2xBNC)
AUDIO INPUT					1
Split Screen					Support Picture in Picture(PIP/POP/PAP)
Power
Power Supply					AC100V~240V
Maximum Power Consumption					250W
Standby Power Consumption					<=3W
Temperature
Working Temperature					0°C~50°C
Working Humidity					20%-80%
Dimension					957.45x550.2mm
Video Wall Controller(Built-in each Screen)
Model No.	US-P816A
Input	CVBS	3*BNC inputs, support PAL/NTSC all formats, 2*BNC loop outputs
	VGA	1*D15 port, support SVGA/XGA/WXGA
	YPbPr/YCbCr	1* YPbPr/YCbCr input, support PAL/NTSC all formats, and 720P,1080I, HDTV
	Y/C	2*BNC inputs, support PAL/NTSC all formats
Output	LVDS	Support signal or double LVDS output, and WUXGA (1920*1080) display
Operate  mode	Panel key operation(needs customization)
	Standard RS232 port( provide free control software)
	Infrared Remote Control Operation
Engineering software	Customized
Working temperature	0~70 °C
working humidity	5~95 %RH
AC voltage power supply	100-240V/50, 60Hz
power consumption	Max 300W,according to different Screen models
Dimension	338×295×60(mm)
Weight	About 3.5KG
