46 Inch Samsung DID LCD Video Wall With Narrow Bezel 7.3mm

46 Inch Samsung DID LCD Video Wall With Narrow Bezel 7.3mm thumbnail-1
46 Inch Samsung DID LCD Video Wall With Narrow Bezel 7.3mm photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER
Model Number:
US-LTI460AA04
Contact Supplier Request Quote Chat Now
Shenzhen USER Special Display Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name USER
Model Number US-LTI460AA04
Type Other, DID
Application Indoor
Panel Size 46 inch
Max Resolution 1366x768
Viewing Angle 178°
Color 16.7M
Contrast Ratio 3000:1
Brightness 700cd/m2
Response Time 6ms
Input Voltage 250W

Specifications

samsung DID screen
narrow bezel

1. Splicing unit (DID LCD screen) specification

Specification model: US-LTI460AA04
Panel size: 46"Samsung DID LCD screen(with narrow bezel 7.3mm)
Display area(mm)/mode: 16:9
Resolution: 1366x768
Color: 8Bit,16.7M
Brightness (nits): 700cd/m2
Contrast: 4000:1
Visual angle: (H/V) 178°
Response time :<=6ms
Life(hrs): >60,000(hrs)

Input and output

Video input: VGA/DVI/HDMI 1
 AV/S-VEDIO/YUV: 1 (option)
Audio input: AUDIO 2 (BNCx2)

Power

Power supply: AC100V-240V
Maximum power consumption: 250W
Standby power consumption: <=3W

Temperature
Working temperature: 0-50degrees
Working humidity: 20%-80%

Appearance

Product dimension( W x H x D) mm :1047.4x600.6x131
Acessory :Cable can supply different kinds of cable

2. LCD Video wall processor (US-VWPXX)specification

Input: CVBS Each one BNC terminal, support PAL/NTSC all formats, as well as HDTV720P,1080I,1080P
RCBHV: Each one D15 port terminal to support SVGA/XGA/WXGA/UXGA
YPbPr/YCbCr: Re-using the above RGBHV interface, support PAL/NTSC ALL FORMATS, AS WELL as 720P,1080I, 1080P

Output: RGBHV Each one D15 port terminal to support SVGA/XGA/WXGA/UXGA
YPbPr/YCbCr: Each 3 BNC terminals,( re-use the above R.G.B of RGBHV),support PAL/NTSC all formats 720P/1080i HDTV
Operate mode: Panel key operation(needs customization)
Standard: RS232 port( provide free control software)
Infrared: Remote Control Operation
Display: unit combination "Can support up to 14 display units by 1 single machine
, multi-machines can be paralleled to control up to 12x14 display units"
Engineering software: Customized
Working temperature: 0-60 degrees
working humidity: 5-95 %RH
AC voltage power supply: 180-240V/50Hz
power consumption: Max 100W/single machine
Chassis Specifications: 4U standard rack chassis( can choose 2U/1U chassis when there are fewer output units)
Chassis Size: 431x264x350(mm)
Weight: about 15KG
