USER Hot Sale 19'' Open Frame for Casino/kiosk, 6.5''-42''

Name: USER Hot Sale 19'' Open Frame for Casino/kiosk, 6.5''-42''
Brand: USER/OEM
SKU: 103441745
Availability: InStock

US$ 1 - 5 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

USER/OEM

Model Number:

KFS-M1901P

Shenzhen USER Special Display Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name USER/OEM

Model Number KFS-M1901P

Type TFT

Application Indoor

Panel Size 19''

Max Resolution 1280x1024

Viewing Angle 170°/170°

Pixel Pitch 0.264mm

Color 16.7M

Contrast Ratio 1000:1

Brightness 300nits

Response Time 5ms

Input Voltage 45W

Specifications
Model No.	KFS-M1901P
Panel size	19" TFT-LCD
Display area(mm)/mode	379(W)×304(H) 4:3
Maximum resolution	1280x1024
Display color	16.7M
Pixel Pitch(mm)	0.264(H)×0.264(V)
Brightness (nits)	300nits
Contrast	1000:1
Visual angle	170°/170°
Response time	5ms
Horizontal frequency	30-75KHZ
Vertical frequency	56-75KHZ
Life(hrs)	60,000(hrs)
Input and output
Composite video input	2 (BNC×2)
YPbPr input	1 (BNC×3)
VGA	1
HDMI	1
Composite video output	1 (BNC×1)
Video
Color system	PAL/NTSC/SECAM
OSD display( screen menu display)
Menu language	Chinese/English
Power
Power supply	AC100V~240V,50/60Hz
Maximum power consumption	45W
Standby power consumption	3W
Temperature
Working temperature	0°C~50°C
Storage temperature	-20°C~60°C
Working humidity	10%~75%
Storage humidity	85%
Appearance
Body dimension(Lx W x H)mm	418.832770
Panel color/appearance	White,black,customized
Case Material	Metal
Net weight	7.1kg
Installation	Open frame
