19"Industrial LCD Monitor
US$ 290 - 340
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER
Model Number:
US-I1901F
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
15"Industrial LCD MonitorUS$ 250 - 350MOQ: 50 Pieces -
19 Inch Industrial Monitor ( Embedded)US$ 300 - 350MOQ: 50 Pieces
-
19 Inch Industrial Monitor ( Rack-mounted)US$ 300 - 350MOQ: 50 Pieces
-
19'' Industrial TFT Lcd MonitorNegotiableMOQ: 5 Pieces
-
15'' Industrial LCD Monitor(Wall-mounted)NegotiableMOQ: 50 Pieces
Place of Origin
Guangdong, China
Brand Name
USER
Model Number
US-I1901F
Specifications
Resolution: 1280*1024Brightness: 350nit
Contrast: 700:1
Viewing angle: 170/170
Response time: 8ms
Specifications:
Model No. |
US-I1901F | |||||||||
| Panel size | 19″TFT-LCD | |||||||||
| Display area(mm)/mode | 376(W)×301(H) 4:3 | |||||||||
| Maximum resolution | 1280x1024 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.294(H)×0.294(V) | |||||||||
| Brightness (nits) | 350cd/m2 | |||||||||
| Contrast | 700:1 | |||||||||
| Visual angle (up/down/left/right) | 170°/170° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Installation | rack-mounted | |||||||||
| Input and output | ||||||||||
| Composite video input | 2(BNC×2) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | 1 (BNC×3) | |||||||||
| S-video | 1 | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| HDMI /DVI (optional) | 1 | |||||||||
| Composite video output | 2(BNCx2) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multiple language supported) | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <45W | |||||||||
| Standby power consumption | <3W | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 482×355×61.5 | |||||||||
| Panel material | metal case | |||||||||
