32'' Industrial Grade Waterproof LCD Monitor

Specification

Model No.

US-AD320LD

Panel size

32″ LED backlight, All New A+ panel

Display area(mm)/mode

700Wx394(H)(mm) 16:9

Maximum resolution

1920*1080

Display color

16.7M

Pixel Pitch(mm)

0.36*0.12mm

Brightness (nits)

400nits

Contrast

6000:1

Visual angle

176°/176°

Response time

5ms

Life(hrs)

50,000(hrs)

Input and output

LAN

RJ45 (for Network version) optional

WIFI

1 (for Network version) optional

USB

1

SD

1

Speaker

2×5W(8Ω)

Video

Color system

PAL/NTSC/SECAM

OSD display( screen menu display)

Menu language

Chinese/English

Power

Power supply

AC100~240V 50 /60 HZ

Maximum power consumption

120W

Standby power consumption

3W

Temperature

Working temperature

0°C~50°C

Storage temperature

0°C~80°C

Working humidity

85%

Storage humidity

85%

Appearance

Color/appearance

White,black,customized

Case

Metal case SPCC

Installation

Wall mount

Tempered glass

4mm

Quality Standard

ISO9001,CCC

Detailed functions:

Video format: MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI

Audio format: Wave/MP3/WMA/AAC

Image format:JPEG/BMP/TIFF/PNG/GIF

Image resolution:480P/720P/1080P

Play mode:Power on, single card auto loop play; classified files auto loop play; multi cards auto loop display etc

Time:year/month/day/week/h/m/s, in the top right corner (open and close optional)

Timing open & close:Per day 5 times, 7 days a week, free time

Timing play:7 days a week, free set the play program everyday

Alarm clock:Set 5 alarms one day, once ring the alarm, play the specified program

OTG:Support copy, delete, remove, rename, build new file among different cards

Running subtitle:Can set the play location, word size, color and back-color

Log files:Record the play time (concise to second), the play contents

Memory function:Power off, memory the time of the play; power on, play from the time, not from beginning

Key and lock function:Use the remote controller before input the keyword

Sound volume:Can set the volume of sound in the different time

Storage card lock:Have a anti-theft lock in the case, equip 2 sets key

Other function:Customized

Upgrade software:Just put the upgrade file in the USB slot
