24 Inch Lcd Hd-sdi Broadcast Monitor
US$ 900 - 2,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
User
Model Number:
US-BC2401
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
User
Model Number
US-BC2401
Specifications
24 inch lcd hd-sdi broadcast monitorDisplay area/mode: 16:10
Maximum resolution: 1920*1200
24 inch lcd hd-sdi broadcast monitor
| Specifications | ||||||||||
| Model No. | US-BC2401 | |||||||||
| Panel size | 24″TFT-LCD | |||||||||
| Display area(mm)/mode | 16:10 | |||||||||
| Maximum resolution | 1920×1200 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.270(H)×0.270(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 1000:1 | |||||||||
| Visual angle | 89/89/89/89 up/down/left/right | |||||||||
| Response time | 8ms | |||||||||
| Input and output | ||||||||||
| Video input / loop out | 1 X BNC | |||||||||
| Y / C input / loop out | 1 X DIN | |||||||||
| Composite (YPbPr / YCbCr) input / loop out | 3 × BNC (can support 1080p format) | |||||||||
| SD / HD-SDI video input / loop out | 2 × BNC HD / SD auto-detection | |||||||||
| Audio input / loop out | 2 × RCA stereo | |||||||||
| Speaker | 3W × 2 | |||||||||
| Remote Control | RS-232 | |||||||||
| Dual screen (PIP / PBP) | yes | |||||||||
| Dual Screen exchange | yes | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM (automatic recognition) | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multi language supported) | |||||||||
| Power | ||||||||||
| Power supply | AC:100-240V 50/60HZ | |||||||||
| Standby power consumption | <=65W | |||||||||
| Power-saving mode | without signal for some time, turn off a number of peripherals | |||||||||
| Temperature | ||||||||||
| Color Temperature | 9300K, 6500K, 5600K, customized | |||||||||
| Mark to select | center marker, the proportion of marked, safe area, filling | |||||||||
| Working temperature | 0°C~50°C | |||||||||
| Appearance | ||||||||||
| Chroma vectors | yes | |||||||||
| Luminance distribution histogram | yes | |||||||||
| Black and white mode | yes | |||||||||
| All blue-mode | yes | |||||||||
| Full scan mode | scanning, over scan | |||||||||
| Display scale | 16:9,4:4, full screen, press the input image ratio of 1:1 (dot to dot) | |||||||||
| TALLY LED lights | red and green color channels highlighted warning lamp | |||||||||
| 24-inch rack mount | optional | |||||||||
| VESA install | VESA MIS-D(100X100mm) | |||||||||
| End blocks | yes | |||||||||
| Battery pinch | yes | |||||||||
| Accessory | Power, SDI cable, screws, manual | |||||||||
| Total weight | about 9.6kg without accessory | |||||||||
