2015 design jiangsu wuxi 4 Roller manual stainless steel pipe bending machine

FOB Price

USD $45,000 - $50,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port SHANGHAI
Payment TermsT/T PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	SC	Model Number	W12-16X2000
Machine Type	Roller-Bending Machine	Raw Material	Sheet / Plate Rolling
Material / Metal Processed	Carbon Steel	Power	Hydraulic
Automation	Automatic	Extra Services	End Forming
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

2015 design jiangsu wuxi 4 Roller manual stainless steel pipe bending machine

Rolling Machine Function:

This machine is the general equipment used for bending plates. Pre-bending and bending can be completed on the machine without U-turn. Plates can be bended to be tubular, arc or even cone-shaped work pieces with supplemental device. Therefore, this kind machine can be widely used in such industries as war industry, source of energy, traffic, petrol, chemical industries, boiler, shipbuilding, hydraulic power, metallic structure, etc.

Feature and advantage

The machine is optimal equipment with four rollers to bend metal plates. Its merits are as follows:

1. Pre-bending and bending can be completed without reversing end for end.

2. After plate fed, alignment can be finished by side rollers.

3. Plate can be leveled sketchily on the machine.

4. Surplus of pre-bending is short and all kinds of defective reel can be regulated.

5. It is convenient to bend cone-shaped work pieces.

Technical parameter:

Specification	W12-16X2000
Useful length (mm)	2000
Min diameter=top roller Φ *5 without prebend	20
Min diameter=top roller Φ *5 with prebend	16
Min diameter=top roller Φ *(1.5-2) without prebend	16
Min diameter=top roller Φ *(1.5-2) with prebend	12
Top roller dia (mm)	280
Bottom roller dia (mm)	260
Sider roller dia (mm)	220
Main motor (Kw)	18.5
Rolling speed (m/min)	3-5
Overall Dimension LWH (mm)	4600x1950x1900 mm
Weight (ton)	9.6

Hydraulic Rolling Machine W12 series Technical parameter
