Hydraulic Plate Rolling Machine SW11-16X3200 and 3 roller symmetry rolling machine Struct function
Its top roller do vertical lift at the center symmetry position of bottom rollers through screw transmission, two bottom rollers rotating provide torque for rolling plate, through joggle of output gear of gear reducer and bottom rollers. The machine needs other assistant equipment for pre-bend plate end.
Feature and advantage:
1) Power driven mechanical rolling machine.
2) Its upper roller do vertical lift at the center symmetry position of bottom rollers through screw transmission;
3) two bottom rollers rotating provide torque for rolling plate, through joggle of output gear of gear reducer and bottom rollers.
4) The machine needs other assistant equipment for pre-bend plate end.
Technical parameter:
Specification |
SW11-16X3200 |
Max plate thickness (mm) |
16 |
Max plate width (mm) |
3200 |
Roll speed (m/min) |
5 |
Min diameter of Max plate thickness (mm) |
850 |
Upper roller diameter (mm) |
340 |
Bottom roller diameter (mm) |
280 |
Two bottom rollers center space (mm) |
440 |
Motor power (kw) |
22 |
Dimension L*W*H (mm) |
5830x1620x1730 |
Hydraulic Rolling Machine SW11 series Technical parameter
