High power 12V ultra high sensitivity vibration adjustable delay switch module vibration alarm with 2 sensors
- 0 per Month
Product Description
30A 12V high power ultra high sensitivity vibration delay module plus relay module plus delay three in one module,Vibration switch module alarm
Use:
Vibration trigger alarm delay, can be directly used for car alarm,Vibration switch, andAll kinds of high current, high voltage occasions.
Module features:
1 with twoSuper high sensitivityVibration sensor;
2 vibration sensors can be connected in the detection position, length of 5 meters in sensitivity to no effect
3 to provide a variety of power input connection, to meet a variety of different needs;
4 with anti - power supply connected to anti - protection diodes, effective protection of products;
5 with a regulated IC, to provide a stable supply of adequate power;
6, the use of high performance timing CPU design, double PCB board;
7, there is a power indicator (red LED) and switch trigger timing instructions (green LED);
8, the output can be connected to AC 30A 30V or DC 30A 250V load;
9, this module isNormally open type vibration sensorWhen.Vibration transducerWhen the module is started.Light green, LED, relay, time end, green LED and release;
10,In the time of the trigger end, in the time of the delay time to receive a vibration trigger signal, the relay has been connected, the relay will not disconnectFlash break,shockTrigger signal after the stop, from the newstartTime, delay time to relay off;
11, there are time potentiometer adjustment time,Product design for 1-180 seconds adjustable, can also be customized time range;
12, timing error in 5%
Module instruction:
Vibration sensorInduction to haveWhen shaking, relayPull, delay start time, at this time, the green lightBright,That is, the public side and often begin to connect,The common end is disconnected from the normally closed end.
Product application:
1, with a variety of other sensor plus relay module, can do a variety of time delay switch, direct with the echange of 220V products;
2, corridor delay switch, delay energy saving products;
3, the ground motion sensor can do all kinds of alarm delay trigger, such as earthquake alarm, anti-theft alarm
4, then vibration sensor can also be applied to auto start automatic trigger control related products;
5, machinery and equipment to stop the delay alarm.
Electrical parameters:
Power supply voltage: 12VDC
Current: more than 100mA
Load: 30A 250V AC or 30A 30V DC
Delivery list:
12V vibration sensor delay module,With ultra high sensitivity vibration sensor 2.
12V vibration delay module wiring instructions:
Delay relay module control AC equipment wiring diagram:
Delay relay module control DC equipment wiring diagram:
Need bo can open the following link to buy, pay attention to is not complete, but can be installed under the board oh.
