Detailed Product Description
die cutting machine
Hydraulic Pressure Moving Head Die Cutting Machine is mainly suitable for cutting one layer or layers of leather, rubber, plastic, paper-board, fabric, chemical fiber, non-woven and other materials with shaped blade.
1. Adopting the structure of gantry framework, so the machine has high intensity and keep its shape.
2. The punch head can automatically move transversely, so visual field is perfect and the operation is safe.
3. Return stroke of the platen can be set arbitrarily to reduce idle stroke and improve efficiency.
4. Using differential oil way, cut is rapid and easy.
| HYL4-250 | HYL4-250A | HYL4-350 | HYL4-350A | HYL4-500 | HYL4-500A |
Serviceable breadth | 1600 mm | 1800 mm | 1800 mm | 2000 mm | 1800 mm | 2000 mm |
Travel head | 500x500 mm | 650x650 mm | 650x650 mm | 760 x 760 mm | 650x650 mm | 760 x 760 mm |
Maximum cutting power | 25tons | 25tons | 35tons | 35tons | 50tons | 50tons |
Stoke adjustable from-to | 5-150 mm | 5-150 mm | 5-150 mm | 5-150 mm | 5-150 mm | 5-150 mm |
Pump motor | 2.2KW | 2.2KW | 3.0KW | 3.0KW | 4.0KW | 4.0KW |
Travel head speed | 1.07 m/sec | 1.07 m/sec | 1.07 m/sec | 1.07 m/sec | 1.07 m/sec | 1.07 m/sec |
Dimensions | 2200 x720x2200 mm | 2400x720x205 0mm | 2500x900x2100 mm | 2700x900x2200 mm | 2500x900x2200 mm | 2700x900x2200 mm |
Net weight, with oil | 1600 Kg | 2100Kg | 2600kg | 3000 Kg | 3800kg | 5000kg |
Main Features:
- Pushbutton controls (time interlock synchronization during cutting phase) to ensure positive safety for the operator
- Really exceptional trolley displacement speed
- High power continuity
- Low energy consumption
- High reliability, no primary maintenance required
- On Demand
Process Picture
*production: (1)we produce hydraulic cuting machine with your own designed logo. (2)supply ability:100 sets/month (3)fast delivery |
*price (1)wholesale price (2)good quality with best price (3)terms of payment: T/T |
*certificate:ISO9001-2008 Approved |
*Market:East Asia,Eastsouth Asia.South America, Mexico,Middle east, East Europe and so on. |
Artwork skills:The second generation hydraulic principle. |
Price term: FOB Shanghai Payment term: T/T
Supply Ability: 100 sets/month MOQ: 1 set
Sample delivery time: 2-3 days
Delivery Time: within 20 days after samples confirmed
Artwork: plane cutting machine, travel head cutting machine, four-column cutting machine and so on .
FAQ:
1.Q:Are you a factory or trading company?
A: Yes,we are a factory. you are most welcomed to visit us .
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Xinghua City, Jiangsu Province, China, about 4 hours from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:Have you ever attended any exhibitions ?
A: Sure.
Sample: 2012 Guangzhou exhubition
4.Q:What is the material of your products?
A: The material is mainly steel. We can also choose material as customers’ requirements.
5.What is the artwork of your products,can print our logo?
A: Yes,we can provide your logo.
6.Q:Can I get some samples?
A: We are honored to offer you samples in advance.
7.Q:How does your factory do regarding quality control?
A: Quality is priority. Huaying people always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO authentication.
Welcome to contact us for more details ,most competitive price for you!
