Cnc Woodworking Machine MJBQ6232A
US$ 12,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Saw, panel saw
Place of Origin:
Guangdong, China
Brand Name:
Xinnianhua
Payment & Shipping
Payment Methods:
Port of Shipment:
Shunde/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MJQ6128G Vertical Panel Saw for SellUS$ 4,000 - 4,500MOQ: 1 Set -
Wood Sliding Panel Saw MJQ6128CUS$ 4,000 - 5,300MOQ: 1 Set
-
Precision Table Panel Saw MJQ6128DUS$ 4,000 - 4,800MOQ: 1 Set
-
Hot!! Wood Cutting Table Saw MJQ6132CUS$ 4,000 - 5,300MOQ: 1 Set
-
Very Useful Furniture Machine MJQ6128GUS$ 4,000 - 4,500MOQ: 1 Set
Type
Other, Saw, panel saw
Place of Origin
Guangdong, China
Brand Name
Xinnianhua
Model Number
MJBQ6232A
Weight
light
Certification
ISO 9001:2008, QS-9000,CE
Specifications
cnc woodworking machine MJBQ6232A1.high precision
2.Max Cutting Length:3250mm
3.high efficiency
4.long service time
cnc woodworking machine MJBQ6232A
USE OF THE MACHINE
The machine is developed and produced with advantage of panel saw,it is a kind of high efficient panel saw equipment with feature of high efficiency,high accuracy,easy operation,less trouble,good safety,low work strength,apply for precisely cuttings of various artificial panel,such as laminating board,flake-board,MDF board,veneer etc.It is extensively used in panel processing in large-middle scale of enterprises.
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER MJBQ6232A
Max processing length |
3250mm |
Max processing thickness 90° |
80mm |
45°tilting max processing thickness |
65mm |
Dia. Of main saw shaft |
Φ30mm |
Dia. Of groove saw shaft |
Φ22mm |
Dia. Of main saw blade |
Φ355mm |
Dia. Of groove saw shaft |
Φ120mm |
Rotary speed of main saw shaft |
4200r/min |
Rotary speed of groove saw shaft |
6800r/min |
Cutting speed |
16-30M |
Motor power of main saw blade |
9kw(12HP) 380V 50Hz |
Motor power of groove saw blade |
0.75kw(1HP) 380V,50Hz |
Working air pressure |
0.6mpa |
Weight of machine |
2200kg |
Overall dimension(L×W×H) |
6180x5680x1550mm |
Dust-collecting mouth external diameter |
Φ100(4")mm |
