AWP-10 Standard Water Moulding Tcu Machine for Industry

Name: AWP-10 Standard Water Moulding Tcu Machine for Industry
Brand: AODE
SKU: 103423149
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Water Temperature Machine

Application:

plastic injection mould,roller,reaction kettle, plate

Shenzhen Aode Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Water Temperature Machine

Application plastic injection mould,roller,reaction kettle, plate

Place of Origin Guangdong, China

Brand Name AODE

Model Number AWP-10

Temperature Range 15℃~120℃

Temperature Control Accuracy PID±1℃

Dimension(L*W*H) 800*325*640mm

Weight 62kg

Internal Piping Size 3/8*4

Voltage 3N380V50HZ

Power(W) 9KW

Certification CE and ISO

After-sales Service Provided Engineers available to service machinery overseas

AWP-10 standard water moulding tcu machine for industry Quick Detail:

Temp. Control accuracy: PID±1℃
Range of temperature control:+15℃-120℃ for incoming water
Certification:CE & ROHS
Controller:microcomputer
Heating capacity: 9KW
Maximum power consumption: 10KW
Alarm function:Excess temperature, open phase, oil starvation, overloading, reverse turn

AWP-10 standard water moulding tcu machine for industry Description:

Explosion-proof equipment(optional)
Air blowing and return water function(optional)
Thermometer for return water
Automatic air-exhausting function after startup
Switchover of heating power
Instant cooling shut-down function(optional)
RS485 communication function for automated management(optional)
BY-PASS pressure release loop for hot water
Customizable multi-point temperature control unit
Customizable horsepower and heating power of water pump
Brands OMRON, FUJI, TE, LG, MOELLER, ABB, and WEST for electric appliances
Range of temperature control: +15℃-180℃for incoming water
Stainless steel integrated pipelines for less pipe resistance and rust
Control mode: imported microcomputer or PLC(optional)
Perfect safety protection, fault display, easy repair and maintenance even free of professionals

AWP-10 standard water moulding tcu machine for industry Specifications:

ITEM	UNIT	AWP-10
Temp control range	℃	Inlet water temperature +15℃-120℃
Temp control accuracy	℃	PID±0.1℃
Power supply		AC3N380V 50HZ 3P+E(5M)
Heat transfer medium		Water
Cooling method		Indirect Cooling
Heating capacity	KW	9
Horsepower of pump	hp	1
Working flow of pump	L/min	100
Working pressure of pump	Kg/cm2	1.6
Max. power consumption	KW	10
Alarm function		Open phase/water depletion/excess temperature/overloading/reverse turn
Cooling water pipe	inch	1/2
Circulating water pipe	inch	3/8×4
Size(L×W×H)	mm	800×325×640
Weight	kg	62
