Specifications
Sunnywei Wood Lathe1) with servo motor
2) 7 inch color LCD screen
3) we are factory
4) G- code and english interface
Sunnywei Automatic Wood Lathe For Sale
USE OF THE MACHINE
It is one of the common equipment that apply in furniture industry and wooden decorative art & craft industry.It mainly use in processing all kinds of shaping retro-rotary work-piece with template or copy shaper for example round bar,whorl pillar Rome pillar, crystal pillar,whorl wood line,wooden stair banister and the back of solid wood chair
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER :
MODEL | MCK3013 |
Max Cutting Length | 1300mm |
Max Cutting Diameter(double cutter) | 200mm |
Max Cutting Diameter(single cutter) | 180mm |
Spindle speed | 700-3500r/min |
Total power/Voltage frequency | 7kw/ 380V 50Hz 3PH |
Consumption of air pressure | 0.6-0.8mpa |
Weight of machine | about 2200kg |
Overall dimensions(L×W×H) | About 3100×1100×1350mm |
Advantage:
1. Alloyed cutting tool, suitable for various softwood and hardwood with smooth processing stroke.
2. laser scanning, transfer NC documents directly
3. Designed with dust chokes for dust collection& environmental protection
4. Ball screw, accuracy reached 0.1m,with free unit increment adjustment, highly expend service life
5. 7 inch color LCD screen
6. CNC processing, can do a variety of shape
7. super stable body , suitable for high speed processing
Thank you for your attention!
