Specifications
Automatic wood machine1.with servo motor
2.with cnc control system
3.can scan the wood shape
4.1.6 working length
Automatic wood machine with feeding Xinnianhua
It is one of the common equipment that apply in furniture industry and wooden decorative art & craft industry.It mainly use in processing all kinds of shaping retro-rotary work-piece with template or copy shaper for example round bar,whorl pillar Rome pillar, crystal pillar,whorl wood line,wooden stair banister and the back of solid wood chair
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER :
MODEL | MCK16016-DA |
Max Cutting Length | 1600mm |
Max Cutting Diameter | 160mm |
Spindle speed | 700-3500r/min |
Total power/Voltage frequency | 9.5kw 380V 50Hz 3PH |
Consumption of air pressure | 0.6-0.8mpa |
Weight of machine | about 2000kg |
Overall dimensions(L×W×H) | About 3200×1700×1500mm |
Advantage:
1.Alloyed cutting tool, suitable for various softwood and hardwood with smooth processing stroke.
2.Unique 3D scanning device transmitted scanned data to control through the accurate scan of master part
3.Designed with dust chokes for dust collection& environmental protection
4.Ball screw, accuracy reached 0.1m,with free unit increment adjustment, highly expend service life
5.Digital control system with LCD, easy operation the turning lathe with conductive instruction
system, simple and convenient application
6.User-friendly operation,NC adjustable speed and stroke control
Images of the mchine
Photos of our company
Certification
