MCK3013-D Automatic Wood Lathe

Specifications

Automatic Wood Lathe
1.with servo motor
2.with cnc control system
3.can scan the wood shape
4.double knives



CNC Wood Lathe For Sale



USE OF THE MACHINE

It is one of the common equipment that apply in furniture industry and wooden decorative art & craft industry.It mainly use in processing all kinds of shaping retro-rotary work-piece with template or copy shaper for example round bar,whorl pillar  Rome pillar, crystal pillar,whorl wood line,wooden stair banister and the back of solid wood chair







MAIN SPECIFICATION AND TECHNOLOGY PARAMETER :

MODEL	MCK3013-D
Max Cutting Length	1300mm
Max Cutting Diameter(double cutter)	200mm
Max Cutting Diameter(single cutter)	180mm
Spindle speed	700-3500r/min
Total power/Voltage frequency	7.5kw(10HP)/380V 50Hz 3PH
Consumption of air pressure	0.6-0.8mpa
Weight of machine	about 1600kg
Overall dimensions(L×W×H)	About  2800×1100×1350mm







Advantage:







1.Alloyed cutting tool, suitable for various softwood and hardwood with smooth processing stroke.



2.With servo motor control, stable working with high speed working. also with G-code ditate and englishe interface.



3.Designed with dust chokes for dust collection & environmental protection







4.Ball screw, accuracy reached 0.1m,with free unit increment adjustment, highly expend service life



5.Digital control system with LCD, easy operation the turning lathe with conductive instruction



system, simple and convenient application



6.User-friendly operation,NC adjustable speed and stroke control



7.Double knives for the machine, more accutacy and smooth, can be choose add the sander wheel



8. A full set of the machine is focus on the heavy duty type, make sure the stable working and durable



9. Can customize for Sprial and beenline shape produce, also can customize making cup.





Pictures of machine







 Thank you for your attention!
