New CNC Lathe For Wood MC3016
It is one of the common equipment that apply in furniture industry and wooden decorative art & craft industry.It mainly use in processing all kinds of shaping retro-rotary work-piece with template or copy shaper for example round bar,whorl pillar Rome pillar, crystal pillar,whorl wood line,wooden stair banister and the back of solid wood chair
MAIN SPECIFICATION AND TECHNOLOGY PARAMETER :
MODEL |
MCK3016 |
Max Cutting Length |
1600mm |
Max Cutting Diameter(double cutter) |
200mm |
Max Cutting Diameter(single cutter) |
180mm |
Spindle speed |
700-3500r/min |
Total power/Voltage frequency |
7.5kw(10HP)/380V 50Hz 3PH |
Consumption of air pressure |
0.6-0.8mpa |
Weight of machine |
about 1800kg |
Overall dimensions(L×W×H) |
About 3200×1100×1350mm |
Advantage:
1.Alloyed cutting tool, suitable for various softwood and hardwood with smooth processing stroke.
2.Unique 3D scanning device transmitted scanned data to control through the accurate scan of master part
3.Designed with dust chokes for dust collection& environmental protection
4.Ball screw, accuracy reached 0.1m,with free unit increment adjustment, highly expend service life
5.Digital control system with LCD, easy operation the turning lathe with conductive instruction
system, simple and convenient application
6.User-friendly operation,NC adjustable speed and stroke control
If still have any question,please contact us freely for more details, we are glad to provide and answer it.
Thank you for your attention!!
