Cement Rotary Kiln Burner and Rotary Kiln Bauxite
US$ 100,000 - 1,600,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Ruiguang Machine
Model Number:
RGHZY-050
Payment & Shipping
Payment Methods:
Port of Shipment:
Qindao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Soil Cement Mixing Equipment in ChinaUS$ 100,000 - 1,000,000MOQ: 1 Set -
Hot Sale Cement and Gypsum Rotary KilnUS$ 100,000 - 1,600,000MOQ: 1 Set
-
Hot Supporting Roller Rotary Cement Kiln and Lime KilnUS$ 100,000 - 1,600,000MOQ: 1 Set
-
Professional Lime Cement Rotary KilnUS$ 100,000 - 1,600,000MOQ: 1 Set
-
Top Selling the Calcination Cement Rotary Kiln for BauxiteUS$ 50,000 - 1,000,000MOQ: 1 Set
Place of Origin
Henan, China
Brand Name
Ruiguang Machine
Model Number
RGHZY-050
Weight
47.5~278t
Cement rotary kiln burner and rotary kiln bauxite
The Introduction of cement rotary kiln
Cement rotary kiln belongs to building material equipment, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.Rotary kiln(cement kiln) is used for making of cement clinker and there are dry and wet methods to make cement. Rotary kiln (metallurgy chemical) kiln is used for magnetic roasting of iron ore and oxidizing roasting of chrome and nickel in the steel factory; baking high-alumina mine in the refractory material factory; baking chamotte and alumina in the aluminum factory and baking chrome ore and chrome powder in the chemical plant.Rotary kiln (lime kilnis) used for baking active lime and dolomite in the steel factory and ferroalloy
factory.
Main characteristics of the cement rotary kiln
1.The lime rotary kiln applied to roast active lime and dolomite which are commonly used in steel factories and ferroalloy factories.
2.The metallurgy chemical rotary kiln is mainly used for magnetized roasting of lean iron ore and oxidizing roasting of chrome ore and nickele ore etc in steel plants.In refractory plants,this rotary kiln is mainly used for roasting clinker and aluminum hydroxide.When used in chemical industry,it is mainly used for roasting chrome ores and chrome powders and more.
3.The cement rotary kiln is primarily used for caining cement cliner,It can be divided into dry process rotary kilns and wet process rotary kilns.
2.The metallurgy chemical rotary kiln is mainly used for magnetized roasting of lean iron ore and oxidizing roasting of chrome ore and nickele ore etc in steel plants.In refractory plants,this rotary kiln is mainly used for roasting clinker and aluminum hydroxide.When used in chemical industry,it is mainly used for roasting chrome ores and chrome powders and more.
3.The cement rotary kiln is primarily used for caining cement cliner,It can be divided into dry process rotary kilns and wet process rotary kilns.
4.These new technologies provide our rotary kiln with strong visual sense, convenient operation and reliable performance. They help stabilize thermal regulation and improve operation efficiency.
5.Comparing with other similar cement production equipment, the operation rate of our rotary kiln increased by 10%, production increased by 5%-10% and heat consumption decreased by 15%.In order to meet customers' requirements, we also provide impact crusher, cone crusher, magnetic separator,flotation machine,ball mill and more.
5.Comparing with other similar cement production equipment, the operation rate of our rotary kiln increased by 10%, production increased by 5%-10% and heat consumption decreased by 15%.In order to meet customers' requirements, we also provide impact crusher, cone crusher, magnetic separator,flotation machine,ball mill and more.
Specification(m) | Kiln dimensions | Output (t/h) | Rotation speed(r/min) | Motor power(kw) | Weight(t) | ||
Diameter (m) | Length (m) | Obliquity(%) | |||||
φ1.4*33 | 1.4 | 22 | 3 | 0.9-1.3 | 0.39-3.96 | 18.5 | 47.5 |
φ1.6*36 | 1.6 | 36 | 4 | 1.2-1.9 | 0.26-2.36 | 22 | 52 |
φ1.8*45 | 1.8 | 45 | 4 | 1.9-2.4 | 0.16-1.62 | 3 | 78.2 |
φ1.9*39 | 1.9 | 39 | 4 | 1.65-3 | 0.29-2.93 | 30 | 77.59 |
φ2.0*40 | 2 | 40 | 3 | 2.5-4 | 0.23-2.26 | 37 | 119.1 |
φ2.2*45 | 2.2 | 45 | 3.5 | 3.4-5.4 | 0.21-2.44 | 45 | 128.3 |
φ2.5*40 | 2.5 | 40 | 3.5 | 9.0-10.5 | 0.442.44 | 55 | 149.61 |
φ2.5*50 | 2.5 | 50 | 3 | 6.25-7.4 | 0.62-1.86 | 55 | 187.37 |
φ2.5*54 | 2.5 | 54 | 3.5 | 6.9-8.5 | 0.48-1.45 | 55 | 196.29 |
φ2.7*42 | 2.7 | 42 | 3.5 | 10.0-11.0 | 0.10-1.52 | 55 | 198.5 |
φ2.8*44 | 2.8 | 44 | 3.5 | 12.5-13.5 | 0.437-2.18 | 55 | 201.58 |
φ3.0*45 | 3 | 45 | 3.5 | 12.8-14.5 | 0.5-2.47 | 75 | 210.94 |
φ3.0*48 | 3 | 48 | 3.5 | 25.6-29.3 | 0.6-3.48 | 100 | 237 |
φ3.0*60 | 3 | 60 | 3.5 | 12.3-14.1 | 0.3-2 | 100 | 310 |
φ3.2*50 | 3.2 | 50 | 4 | 40.5-42 | 0.6-3 | 125 | 278 |
Welcome customers all over the globe to contact us! We sincerely welcome you to visit our company!
