Characteristics of solar battery:
Battery Specification
Specifications Of china battery manufacturer agm battery 12v100ah : | ||
Nominal Voltage |
12V |
|
Rated Capacity (10 hour rate) |
100AH |
|
Size (Length*Width*Height*Total Height) |
406*173*210*230MM |
|
Weight Approx |
29.8KG |
|
|
Capacity 25°C (77°F) |
10 Hour Rate(9.0A) |
100AH |
5 Hour Rate(14.4A) |
80AH |
|
1 Hour Rate(54.0A) |
60AH |
|
1.5 Hour Discharge To 10.5V |
40A |
|
Internal Resistance |
Full Charged Battery at 25°C(77°F) |
5mΩ |
|
Capacity Affected By Temperature (10 Hour Rate) |
40°C(104°F) |
102% |
25°C(77°F) |
100% |
|
0°C(32°F) |
85% |
|
-15°C(5°F) |
65% |
|
|
Self-Discharge at 25°C (77°F) |
Capacity after 3 Month Storage |
91% |
Capacity after 6 Month Storage |
82% |
|
Capacity after 12 Month Storage |
64% |
|
Terminal |
T16 |
|
|
Cycle Charge (Constant Voltage) |
Initial Charging Current Less Than 40A |
|
Voltage 14.40-14.80V Time 14~16h | ||
|
Float Charge (Constant Voltage) |
Voltage 13.50-13.80V |
|
Warranty |
2 Years |
|
OEM Service |
Accept |
|
Color |
Black, Gray |
|
Certificate |
CE; UL; ISO9001; ISO14001; TLC; Solar Product Certificate |
|
1. Excellent safety performance: No electrolyte leakage, battery swelling and cracking under normal use.
2. Good discharging performance: With smooth discharging voltage and mild discharging platform.
3. Good shock-proof performance: The fully charged and completely fixed battery, with 4mm amplitude and 16.7HZ frequency do have a normal open circuit voltage without leakage, batteries swelling or cracking problem after one-hour vibration.
4. Good impact-proof performance: The fully charged battery is proved to maintian normal open circuit voltage and be without leakage or batteries swelling or cracking after droping three times from 20cm height naturally to a 1 cm-thick hardwood board.
5. Good resistance to overdischarge: In temperature of 25 degrees Celsius, the fully charged battery discharges with fixed resistance which is equivalent to the one required by 1 CA discharge of the battery for three weeks, and it can restore capacity over 75%.
6. Good resistance to overcharge: The fully charged battery is proved to maintian normal open circuit voltage and be without leakage or batteries swelling or cracking in temperature of 25 degrees Celsius after chargeing at 0.1 CA for 48 hours, and the capacity maintian over 95%.
7. Good resistance to high current: The fully charged battery is proved to be without conductive part melted or any appearance deformation after discharging at 2 CA for 5 minutes or 10 CA for 5 seconds.
Application
- Alarm System
- Cable Television
- Communication Equipment
- Control Equipment
- Security System
- Medical Equipment
- UPS
- Power Tools
- Toys
- Emergency Power System
