1700 degree C box furnace, larger chamber, PID control

Specifications

box furnace,Heating element,efficiency and long work service.
Polycrystalline alumina fiber stable and no transformation.

1700 degree C box furnace, larger chamber, PID control , Heated  by MoSiO2 Heating Elements









SXL-1700 Box type electric lab furnaceis adopted imported high quality silicon molybdenum rod as heated

element; it adopts the dual shell structure and intelligent auto-control temperature system, SCR control, phase

shifting trigger. The chamber is adopted the 1700 type imported polycrystalline alumina fiber. Equipped with

cooling system between the dual shell, which can rise and cool swiftly; Using constant current soft-start

control, to extend the life of heating elements.







1. Furnace chamber adopted imported alumina polycrystalline fiber, with good insulation and durability properties; And adopted the imported silicon molybdenum rod as heating elements, greatly improving the service life;

2. With unique furnace design , durable to use, does not collapse;

3. Side open type furnace door, open the door power outages;

4. Reserved 485 converter interface, can remote control of single or multiple furnace through software and Internet, real-time tracking , history recorder, output statements; can install the paperless recording device for data storage and output;

5. Over-temperature alarm and power failure, leakage protection, safe and reliable operation.







Universities, research institutes, industrial and mining enterprises to do the powder sintering, sintering of ceramics, high temperature experiments, material handling, quality inspection purposes.











Model	SXL-1700	SXL-1700	SXL-1700
	Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1
Power supply	AC220V 50/60HZ	AC220V 50/60HZ	AC380V 50/60HZ
Furnace chamber    (D x W x H)	160*150*150mm	300*200*200mm	400*300*300mm (Customizable)
Overall size	620*620*900mm	620*680*1050mm	640*760*1600mm
Rated power	4kw	6KW	14KW
Weight	150kg	150kg	400kg
Furnace chamber	1700 type imported alumina polycrystalline fibers furnace chamber, scientific design and with durable, good insulation properties.
Heating elements	imported high quality silicon molybdenum rod
Temperature control components	B-type double platinum rhodium thermocouple
Temperature control mode	The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 50 the heating and cooling program
Working temperature	≤1600℃
Maximum temperature	1650℃
Recommended heating rate	10℃/min
Constant temperature accuracy	±1℃
Standard accessories	Door brick, crucible tongs, oven gloves each one piece
Optional accessories	Furnace hobs, a variety of corundum crucible, computer control software and paperless recorder, etc.
