Product Description:
The coil lacing machines are used by manufacturers of electric motors to lace the stator end coils. Several different models of coil lacing machines are available to lace a wide variety of stator sizes. Some lacing machine models utilize rugged mechanical cams for high-speed lacing of long production runs. Others use servo motors to allow rapid machine change over to accommodate short runs of many different stator sizes.
These coil lacing machines are available in basic, manual operator attended form, or they can be configured with a wide variety of features and options for automation of many functions. Single-end lacing machines are available to lace each coil end separately, and double-end lacing machines are available to lace both coil ends simultaneously. Several different control systems are available, including popular industrial PLC
Main Parameter of Single-head Tie Line Machine
Stator core O.D. |
≤250mm |
Stator stack height |
≤160mm |
Stator core I.D. |
≥30mm |
Lacing mode |
Slot-by-slot/slot-skipping |
Lacing speed |
0.5-0.7 S/Needle |
Air pressure |
0.4-0.7Mpa |
Power supply |
220V/50-60Hz |
Power |
2kw |
Dimension (L×W×H) |
1270mm×650mm×1100mm |
Weight |
≈500kg |
Pictures of Single-head Tie Line Machine
Single-station vertical Wire Winding Machine
Coil inserting machine
Paper inserting machine
Lacing machine
Wire Winding Machine After Packing
Welcome to contact with us!
FAQ
1. How does XTY control the quality of the formed coil?
Our coil winding system consists of the parts like foot pedal control valves, pressure gauges and pressure plates. An engineer can control the winding speed, tougue, tension during the winding process. The gauge provides accurate tension readings during the winding process. The pressure plates within the tension system protect the wire insulation from getting damaged. All these features are used to make best quality coils.
2. How do transformer coil winders work?
Transformer winders consists of a microprocesser and and stepper motor to creat high winding speed. A spool of wire is affixed to the spool arm, and the wire is placed along tiny rollers for smooth movement. Winding parameters such as speed, wire pitch, turns and section winding are programed to the machine. Once the machine is swithed on, it begins the winding process.
Why Choose US?
1.Factory Based,competitive price. We are factory ourselves, We offer you directly factory price.
2. Big Production Capacity. Our factory covers an area of 40 acres with capacity of 3500 sets of Winding Equipment per year.
3.Long Factory History. Our factory have more than 8 years of experience in motor coil winding field.
4.Strategic Location. Our factory only 3kw to highway entrance. From factory to Xinzhen Airport only 1 hour drive by highway.
5. Latest Technology & Professional Engineering Team. Members of our technician team used to study abroad to update their knowledge.
6.Strice Quality Control System. Quality and Service is our core mission.
7.Experienced International Sales Team. Our sales mostly have been in international trading for over 5 years. Fluet in spoken English,Fast in response, customers' concern is always our concern.
8.Rich overseas project experience. We had customers from India, Turkey, Africa, South America,
America etc. To create value for customers is our infinite pursuit.
9.Timely Delivery and Guaranteed after-sale Service. Long-term cooperation with big logistic companies and shipping companies enabled us to deliver the machines as soon as possible. We send engineers abroad every year for assembling and technical support for customers.
