High Performance-Price fridge Stator Coil Inserting Machine

Specifications

Fridge Stator Coil Inserting Machine
1embedded motor iron core coil machine
2 it is used for induction motor



   Fridge Stator Coil Inserting Machine



1, Overview of  Fridge Stator Coil Inserting Machine



  Fridge Stator Coil Inserting Machine is a kind of embedded motor iron core coil machinery production equipment, this machine is used for induction motor stator which meet the specification in the below form date





 Specification of Fridge Stator Coil Inserting Machine:



Stator stack heihgt	5mm-110mm
Max.stator O.D	160mm
Stator I.D.range	17mm-98mm
Displacement of oil pump	/
Air pressure	0.5-0.8Mpa
Power supply	380V/50Hz
Power	2.5Kw
Dimension (L×W×H)	1500mm×740mm×1600mm
Weight	Around 1000kg







2.Benefits of Fridge Stator Coil Inserting Machine



(1) Fridge Stator Coil Inserting Machine includes misuse of personal safety and product safety protection devices

(2) Fridge Stator Coil Inserting Machine has memory function after power energizing, so unfinished work before power outage can continue to complete

(3) When equipment failure occurs, the man-machine interface display fault alarm prompt, it is convenient for maintenance

(4 The mold can be removed in order to change the category of an embedded line

(5)Human-Computer interaction is good

(6)Mold is made by high toughness mold steel

(7) Linkage start switch ensures safety of operator





High Quality Mould of  Fridge Stator Coil Inserting Machine



3.Construction of Fridge Stator Coil Inserting Machine



Fridge Stator Coil Inserting Machine includes mechanical transmission system, frequency control system, PLC integrated control system, touch screen and mold.



(1) If the technical parameter and stator model is same, this machine can automatically insert copper wire and aluminium wire



(2).Production shift ≤16s/set (exclude the man-hours for auxiliary work)



(3) Qualified rate of wire inserting per time ≥98.5%, after modification, qualified rate ≥99.5%





  Fridge Stator Coil Inserting Machine Loading Process



  Fridge Stator Coil Inserting Machine Shipping Process



 4,Other Type of Fridge Stator Coil Inserting Machine

  Fridge Stator Coil Inserting Machine





  Fridge Stator Coil Inserting Machine
