Podoor PB740, Bluetooth Lossless Audio Receiver, HiFi Quality Bluetooth Receiver

Name: Podoor PB740, Bluetooth Lossless Audio Receiver, HiFi Quality Bluetooth Receiver
Brand: podoor
SKU: 103381279

US$ 33 - 36 MOQ: 500 Pieces

Key Specifications

Brand Name:

podoor

Model Number:

PB740

Place of Origin:

Guangdong, China

Shenzhen Ptah Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name podoor

Model Number PB740

Place of Origin Guangdong, China

Specifications

Supported receive fine music from phone, pad, laptop by wirelessly, play via home theathre,enjoy HiFi quality so easy

Product Features:

Simple to use, can easily realize the wireless play from mobile phone, tablet computer to sound box
Adopts top-level blue-tooth transmission and audio processing chip, provides HIFI sound
Tone quality has been optimized specially for iPhone and iPad of Apple
Small size for saving space, easy to be placed

Introduction for Use:

RCA interface of left and right channel is the output interface of audio signal, which can be directly connected with amplifier or the audio input interface of active loudspeaker
The products is equipped with switching line of RCA switching to 3.5mm earphone interface, used for connecting earphone and computer sound box
After the product is electrified, turn on blue-tooth function of the mobile phone or tablet computer, search the blue-tooth device named “podoor”
Connecting “podoor”, match code is four zore “0000”. If it is failed to be connected, please pull the plug, try to connect again after the power has been turned on.

Technical Parameters:

Spec of Bluetooth	Bluetooth V2.1+EDR Compatible V2.0, V1.2, V1.1
Frequency Range	2.4~2.48GHz
Modulation	GFSK, 1Mbps, 0.5BT Gaussian
Maximum Data Transfer Rate	Asynchronous: 723.2kbps/57.6kbps Synchronous: 433.9kbps/433.9kbps
Hopping	1600hops/sec, 1MHz channel space
RF Output Impedance	50ohms
Crystal Frequency	26MHz
Bluetooth Protocol Supported	OPP, OBEX, SPP, A2DP, AVRCP, FTP, HS/HF, DUN Profiles
Operation Distance And Range	10 meters (33 feet) Class Ⅱ
Receiver Sensitivity	-80dBm 0.1% BER
Transmit Power	<4dBm
Connection	Point to Multi-Point
Audio Performance	High acoustic fidelity sound
Audio Encoding Bit	16bits
Signal to Noise Ratio	>90dB
Audio encryption Algorithm	128bits
Temperature Range	-40°C to +80°C
Humidity Range	10%~90% Non-Condensing
Certificate	BQB, CE, FCC
