Industrial collapsible wire stillage cage
Specification of stillage cage
| Same design, defferent sizes | |||||
| Model No. | Exterior dimension |
Wire Guage |
Dimension of Grid |
Loading capacity |
Loaded in 1*40'GP |
| LxWxH(mm) | mm | mm | kg | sets | |
| W-1 | 1030x840x850 | 6 | 50*50 | 1300 | 470 |
| L-1 | 1030x840x850 | 6 | 50*50 | 800 | 470 |
| W-2 | 1230x1040x890 | 6.2 | 50*50 | 1700 | 320 |
| L-2 | 1230x1040x900 | 6.2 | 50*50 | 1200 | 320 |
| S-1 | 1230x1040x950 | 6.2 | 50*50 | 1700 | 320 |
| W-3 | 1030x840x500 | 6 | 50*50 | 800 | 470 |
| Material | Mild steel Q235 | ||||
Available design |
Top lid/bar runner/forklift guide/with inner divider | ||||
Available accessories |
Wheels/inner PP sheet or PP hollow sheet/bag | ||||
Application area |
Warehouse, logistic, recycling industry | ||||
| Finish | Zinc/hot dip galvanized/powder coating | ||||
| Remark | Costomized or OEM support | ||||
Product Features |
1.Collapsible-save space when not in use,ideal for return journeys ventilation and cleaness. |
||||
Details and available designs
Save space: foldable and stackable
Can be designed with runner bar/forklift guide/wheels
Application, packaging & loading
Other kinds of stillage cage for your choices
Gold supplier of Alibaba
Over 20 years manufacturing experience
Skilled and highly controlled working process
Dalian Huameilong Metal Products Co.Ltd , established in 1993,one of the largest manufacturers of transportation security facilities, material handling equipments and welded wire mesh products in North China.We have already
past the ISO 9001:2000 and B&V international well-known certification.
Corporate Culture: Quality is enterprises’ life and motivation and should be guaranteed by whole workers
1, What is the material being used for your products?
---Mild steel Q235, Q195
2, How is the goods being packed?
---Plastic banding + Stretch film wrapped, palletized for easy loading and unloading with standard forklift
truck or pallet jack.
3, What is the payment terms I can get?
---TT or L/C at sight, DP etc
4, What kind of finish do you provide for your goods?
---A.Electro galvanized/Zinc plated: the zinc serves as a sacrificial anode( indoor storage)
B.Hot dip galanized: it forms a coating of corrosion-resistant zinc(indoor/outdoor and cold storage)
C.Powder coating: a type of coating that is applied as a free-flowing, dry powder(indoor/outdoor storage)
5, What is the loading capacity?
---In general, we have light duty(100~300kg) model,medium duty(400~800kg) model and
heavy duty(1000~1700kg) model available for your choice.
6 Which product can be used in cold storage?
---Mobile rack,wire container and roll cage are all widely used in cold storage.
7 I like your design, but couldn‘t find the right model from the products list, is custom size available?
---Yes, we do custom products and projects.
8 I would like to have my own design products and qty is not that big, is it ok?
---Yes, we can go with your custom design, no matter small or big qty, however, pls understand the cost
will be different.
9 I don't have drawing or picture available for th custom products, could you design it for me?
--Yes, we can make the best suitable design for you but do need to know the details, such as
a) dimension b) loading capacity c)stackability d)operation environment
10 What is the minimum quantity I can order?
--1x20'GP - qty is variable depend on the size
11 What is your average production lead time?
--2-3 weeks against formal order and deposit.
12 Do I get any guarantee from your company?
-3~10 years warranty in case that A) Proper handling during operation, correctly forklift handling while
stacking/unstacking B) Overloading is prohibited C) Environment request indoor, dry and not humid
circumstance, do not contact with any corrosive chemical material (for zn plated and powder coated proucts,
no limitation for hot dip galvanized)
Contact Person:
Mary Kong
Dalian Huameilong Metal Products Co.,Ltd.
Tel: 86-411-83615995
Skype: maryk901
