1,Size of H13 Hot Die Steel | ||||||||
Round bar |
Diameter(mm) |
Length (mm) |
|
|||||
Max:800 |
Max:9000 |
|
||||||
Plate |
Thickness(mm) |
Width (mm) |
Length (mm) |
|||||
Max:800 |
Max:1500 |
Max:6000 |
||||||
The specification can be customized. | ||||||||
2,Chemical Compositons | ||||||||
Grade |
C |
Si |
Mn |
P |
S |
Cr |
Mo |
V |
H13 |
0.32-0.45 |
0.80-1.20 |
0.20-0.50 |
≤0.030 |
≤0.030 |
4.75-5.50 |
1.10-1.75 |
0.80-1.20 |
4Cr5MoSiV |
0.33-0.43 |
0.80-1.20 |
0.20-0.50 |
≤0.030 |
≤0.030 |
4.75-5.50 |
1.10-1.60 |
0.30-0.60 |
1.2344 |
0.33-0.41 |
0.80-1.20 |
0.25-0.50 |
≤0.030 |
≤0.020 |
4.80-5.50 |
1.10-1.50 |
0.30-0.50 |
| SKD61 | 0.35~0.42 | 0.80-1.20 | 0.25-0.50 | ≤0.030 | ≤0.020 | 4.80-5.50 | 1.00-1.50 |
0.80-1.15 |
3,Features of H13 Hot Die Steel | ||||||||
1, Hot work tool steel | ||||||||
2, Very good red-hardness with toughnes | ||||||||
3, Tools may be water-cooled in service | ||||||||
4, May be cold-hobbed in the annealed condition | ||||||||
4,Typical Applications | ||||||||
1, Casting dies for aluminium, magnesium and zinc | ||||||||
2, Extrusion dies and adaptor ring | ||||||||
3, Hot stamping and press forge dies | ||||||||
4, Shear blades for hot work and hot swaging dies | ||||||||
| The container is usually 20 ft |
|
| Songshun Company Introduction |
|
|
Main products | |
Hot work tool steel |
|
DIN |
1.2344,1.2343,1.2365,1.2581,1.2367,1.2714 etc. |
AISI |
H13,H11,H10,H21,L6 etc. |
JIS |
SKD61,SKD6,SKD5,SKT4 etc. |
|
Cold work too steel |
DIN |
1.2601,1.2379,1.2080,1.2363,1.2842,1.2419,1.2510,1.2550,1.2767 etc. |
AISI |
D2,D3,A2,O2,O1 etc. |
JIS |
SKD1,SKD11,STD12,SKS31,SKS3 etc. |
|
Plastic mould steel |
DIN |
1.2083,1.2311,1.2312,1.2316,1.2738 etc. |
AISI |
P20, P20+Ni,P20+S,420 etc. |
JIS |
NAK80 |
|
High speed tool steel |
DIN |
1.3355,1.3343 |
AISI |
T1,M2 |
JIS |
SKH2,SKH51 |
|
Structural alloy steel |
DIN |
1.7225,1.6511 |
AISI |
4140,4340 |
JIS |
SCM440 |
We also supply customized special steel, contact us for more information ! | |
|
1.Q:Are your a factory or a trading company? A:We are factory. 2.Q:Where is your factory located?How can I visit there? A:Our factory is located in Dongguan city,you can fly to Baoan airport and we will arrange people to go there pick you up. 3.Q:How can I get some sample? A:We are honored to offer you samples 4.Q:What are the difference between you and other steel company? A:Quality first! The price will be changed according to your order. The rechargeable sample's will return to you after you offer the deposit! Our company are full of chinese culture,Won't you want to come here^.^? The sales are beautiful and handsome0.0! |
|
