Cold Work Mould Steel D3/1.2080/SKD1 Chemical Composition

Name: Cold Work Mould Steel D3/1.2080/SKD1 Chemical Composition
Brand: SongShunSteel
SKU: 103322291
Availability: InStock

US$ 100 - 2,000 MOQ: 20 Tons

Key Specifications

Steel Grade:

Cold Work Steel

Standard:

AISI, ASTM, BS, DIN, GB, JIS

Dimensions:

Dia:20~600mm

Dongguan Songshun Mould Steel Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade Cold Work Steel

Standard AISI, ASTM, BS, DIN, GB, JIS

Dimensions Dia:20~600mm

Place of Origin China

Brand Name SongShunSteel

Model Number D3/1.2080/SKD1/Cr12

Technique Other, Hot Rolled, hot rolled or Forged

Application Die Steel Bar

Alloy Or Not Is Alloy

Special Use Mold Steel

Type Alloy Steel Bar

Product Description

1,Size of D3/1.2080/SKD1 cold work steel
Round bar		Diameter(mm)			Length (mm)
		Max:800			Max: 9000
Plate		Thickness(mm)			Width (mm)		Length (mm)
		Max:800			Max:1000		Max:6000
The specification can be customized.
2,Chemical Compositons
Grade	C	Si	Mn	P	S	Cr	W	V
Cr12	2.00-2.30	≤0.40	≤0.40	≤0.030	≤0.035	11.50-13.00	-	-
D3	2.00-2.30	0.10-0.60	0.10-0.60	≤0.030	≤0.030	11.00-13.50	≤1.00	≤1.00
1.2080	1.90-2.20	0.10-0.60	0.20-0.60	≤0.030	≤0.030	11.00-13.00	-	-
SKD1	1.90-2.20	0.10-0.60	0.20-0.60	≤0.030	≤0.030	11.00-13.00	-	≤0.30
3,Features of D3/1.2080/SKD1 Steel
1, High carbon high chromium tool steel;
2, High wear and abrasion resistance;
3, High resitance to heavy pressure;
4, Immune from sinking in use;
5, Good machinability and inoxidizability.
4,Typical Applications
1, Complex blanking and forming tools;
2, For brick and tile mould liners;
3, Master hobs for cold hobbing plastic moulds;
4, Tabletting punches and sleeves for corrosive powders.

Packaging & Shipping

The container is usually 20 ft

Company Information

Songshun Company Introduction

Main products
	Hot work tool steel
DIN	1.2344,1.2343,1.2365,1.2581,1.2367,1.2714 etc.
AISI	H13,H11,H10,H21,L6 etc.
JIS	SKD61,SKD6,SKD5,SKT4 etc.
	Cold work too steel
DIN	1.2601,1.2379,1.2080,1.2363,1.2842,1.2419,1.2510,1.2550,1.2767 etc.
AISI	D2,D3,A2,O2,O1 etc.
JIS	SKD1,SKD11,STD12,SKS31,SKS3 etc.
	Plastic mould steel
DIN	1.2083,1.2311,1.2312,1.2316,1.2738 etc.
AISI	P20, P20+Ni,P20+S,420 etc.
JIS	NAK80
	High speed tool steel
DIN	1.3355,1.3343
AISI	T1,M2
JIS	SKH2,SKH51
	Structural alloy steel
DIN	1.7225,1.6511
AISI	4140,4340
JIS	SCM440
We also supply customized special steel, contact us for more information !
