Help CenterAutomatic Reel Material Screen Printing Machine for Frequency Passive Tags
Related Products
-
Multi-function Screen Printing Machine for Electronic Sensor TagUS$ 20,000 - 40,000MOQ: 1 Set -
Humanized RFIN Label Tag Screen Printing Machine for Good SaleUS$ 30,000 - 50,000MOQ: 1 Set
-
RFID Screen Printing MachineUS$ 32,000 - 62,000MOQ: 1 Set
-
Screen Printing Machine for Electronic Sensor TagUS$ 32,000 - 62,000MOQ: 1 Set
-
RFID Tag Screen Printing EquipmentUS$ 32,000 - 62,000MOQ: 1 Set
Model No. |
LTA-460 |
Printing material thickness |
0.02-0.5 mm |
Screen Frame Area |
700x870mm |
Squeegee angle |
0-30° |
Max. Print Area |
460x560mm |
Frame regulating variable |
60 mm |
Max. Paper Width |
470mm |
Bench height |
980 mm |
Printing Speed |
20-70 t/min |
Height of screen frame |
|
Power |
Main Drive Motor |
0.75kw |
|
Pulling Drive Motor |
1.5 kw |
||
Air Suction Motor |
0.7kw |
||
UV Drier UV |
5.5x2kw (optional) |
||
Machine Weight |
Net Weight |
1000kg |
|
Gross Weight |
1200kg |
||
Power |
220V 3KW (single-phase power) |
||
Remark: can be designed against your need | |||
Machine Size |
L2850 x W1000 x H1760 mm |
||
Packing size |
L2950 x W1100 x H1630 mm |
||
1. Adopt Japan servo motor and CNC built-in computer control system.running stability, high precision,high torque,fast speed and wear resistance.
2.Adopt Mitsubishi (Japan) frequency converter and adjusting device,easy to regulate speed, 20-70 prints/minute
3.Import Germany magic eye,good for color match and accurate.
4.Pre-set the quantity of sheets by electronic counter.QC lamp for chromatism.
5.Photo sensor auto-detection system for no films.
6.Double-sided scraper,extend service life.
7.Electrostatic painting,stoving varnish and solvent-resistance on the surface of machine.
8.Connecte to corona/die-cutting/slittingQC/ UV dryer and rewinder machine accroding to actual situation.
9.Only one person to operate,replace traditional and semi-automatic method.Improve six times of production efficiency, which reduce cost effectively.
Exclusive by casting structure, the machine
Printing materials:
PVC,PET,PP,PC,PE ,BOPP(ect roll film);IMD,IML,FPC,appliance nameplate,membrane switche,soft circuit board,;heart transfer film, water labeling,thermal transfer paper, adhesive lable or sitcker;ceramic decal, non-woven faric etc.
Automatic feeding machine(double-side dedusting,removing film,electrostatic eliminating→)automatic pringing(punching,printing,QC)oven→automaticdeviation-correcting,rewinding and coronaing machine→automatic punching/cut machine.
Q: Are you manufactory or trade compamy?
A: We are the manufactory in Xiamen,Fujian province,China
Q: Can you make particular design according to our requirements?
A: Yes,we can make a special change according to your requirement.
Q: What’s the covering area of complete equipment,and how many worker for the whole process?
A: About 7 minters length 3 minters width,only 1-2 people to operate. directly save costs.
O: What’s the speed of your equipment?
A: 20-70 print per minute(about 20 meters), about 3000 papers/hour. More than 6 times of production efficiency than semi-automatic.
Q: What are your payment terms?
A : 30% deposit and balance T/T against copy of Bill of Landing or L/C at sight.
Q; Where certificate can you pass?
A: CE, IAF and ISO90001:2008.
Q: What is your company’s production capacity?
A: 30 Set/ Set/ Month
TEL:86-13559215189
FAX:86-592-3780909
Website: / http://xmlingtie.cn.china.cn
We will offer you the quotation as soon as possible once receive your inquiry.
pls don’t hesitate to contact us.
