Product Description
Features
Electrophoresis: Base on anodized process, an extra transparent film is formed to make the surface clearer and look bit of shining, with very good corrosion resistance.
Products popularly applied in areas such as America, Middle East, Africa and Asia.
Professional data of the product
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Other |
Remain |
6005 |
0.6-0.9 |
0.35 |
0.1 |
0.1 |
0.4-0.6 |
0.1 |
0.1 |
0.15 |
Aluminum |
6060 |
0.3-0.6 |
0.1-0.3 |
0.1 |
0.1 |
0.35-0.6 |
0.05 |
0.15 |
0.15 |
Aluminum |
6061 |
0.4-0.8 |
0.7 |
0.15-0.4 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
Aluminum |
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.15 |
Aluminum |
The test report of the quality
Series |
|
Alloy-temper |
6063-T5 |
Category |
Basic |
Standard |
GB5237.1-2008 |
||||
|
Chemical composition |
Element |
Mg(%) |
Si(%) |
Fe(%) |
Cu(%) |
Mn(%) |
Zn(%) |
Ti(%) |
Al(%) |
||
National standard |
0.45-0.9 |
0.2-0.6 |
≤0.35 |
≤0.1 |
≤0.1 |
≤0.1 |
≤0.1 |
Rest |
|||
Check result |
0.55 |
0.43 |
0.215 |
0.018 |
0.0324 |
<0.01 |
0.021 |
Rest |
|||
Inspection item |
Standard requirement |
Check result |
Evaluation |
||||||||
|
Mechanical performance |
Tensile strength (Mpa) |
≥160 |
215 |
Qualified |
|||||||
Yield strength (Mpa) |
≥110 |
135 |
Qualified |
||||||||
Tensile strength (Mpa) |
≥8 |
12 |
Qualified |
||||||||
Wechsler hardness (HW) |
≥8 |
10 |
Qualified |
||||||||
Factory introduction
1. Factory size:Above 300,000 square meters with 44 press production line, from 600ton-4000ton
2. Production capacity:10,000 Ton per month
3. Alloy available:alloy 6063 / 6061 / 6060 / 6005 are available subject to final design
4. Maximum size available:Outside diameter of 400mm
5. Die/Mould ready day:7 to 10 days after down payment & drawings are confirmed.
Ordering process
Samples—→Drawings confirmed—→Die/Mould Making—→Samples and color confirmed—→Mass production
1. Make the drawings within 5 days
2. Make the Die/Mould and tooling in about 2-3 weeks
3. Confirm the new samples and the color
4. Mass production will be finished in about 2-3 weeks subject to quantity and details.
Application
It’s widely used for window, door, furniture, construction, decoration, machine, etc.
CNC precessing ability
Drill holes, stretch bending, milling, welding, fabrication etc.
Typical shapes:
Production Flow
Quality Test
Certificates
