MP3000 Planetary Concrete Mixer(3000L)

Specifications

MP3000 Planetary Concrete Mixer(3000L)
1.Capacity: 3000L
2.Usage: Precast, High-Performance Concrete
3.Certificate: ISO, CE

MP3000 Planetary Concrete Mixer(3000L)





Model:



Item	MP3000
Output Capacity (L)	3000
Input Capacity (L)	4500
Input Capacity (kg)	7200
Mixing Power (kw)	110
Discharging Power (kw)	4
Planet/Paddle	3/9
Side Scraper	1
Bottom Scraper	2
Weight (kg)	11000



Application:



It is widely used to produce:

1.      Common commercial concrete

2.      Precast concrete

3.      High-performance concrete, etc.





Introduction:



1.     Skip Hopper: To elevate aggregate



2.     Mixing Device: To mix precast concrete, common commercial concrete, high-performance concrete, etc.



3.     Discharging Device: Can be discharged by hydraulic, pneumatic or hands





4.     Gearing System: Fluid clutch between motor and gearbox makes the mixer work normally even in the full-load condition.





5.     Observing Port: Can observe the mixing condition no needing turning off power



Quality Control (QC):



1. Third  Control

2. ISO9001:2008 Certificate

3. European CE Certificate

4. Enviroment Protection Design



Commercial Terms:



1. Delivery Time : 20-30 Working Days

2. Payment Term : T/T, L/C, etc.

3. Transportation : By sea or Railway in Container.



After-Sale Service:



1.      Turn-Key Solutions

2.      Erection & Commissioning Service

3.      Operation Training Service

4.      Spare Parts Supply ( all working life )
