Help CenterHZS150: Stationary Concrete Mixing Plant (150m3/h)
Related Products
-
YZHS35 Ready-mix Concrete/cement Plant(35m3/h)US$ 110,000 - 120,000MOQ: 1 Set -
YHZS50 Mobile Concrete Batching Plant (50m3/h)US$ 140,000 - 150,000MOQ: 1 Set
-
YHZS75 Mobile Batching Plant (75m3/h)US$ 160,000 - 170,000MOQ: 1 Set
-
JS750 Twin Shaft Concrete Mixer(35m3/h)US$ 6,000 - 50,000MOQ: 1 Set
-
JS1000 Twin Shaft Concrete Mixer(50m3/h)US$ 6,000 - 50,000MOQ: 1 Set
Specifications
HZS150: Stationary Concrete Mixing Plant (150m3/h)1. Use: Mix Concrete
2. Warranty: 15 Months
3. Certificate: CE, ISO
HZS150: Stationary Concrete Mixing Plant (150m3/h)
Application
It is widely used to produce common commercial concrete, wet concrete, dry-hard concrete, plastic concrete, etc.. It can be used to build road, bridge, dam, house and etc.
Model
Model |
HZS150 |
|
Capacity (m3/h) |
150 |
|
Mixing Time (s) |
60 |
|
Discharging Height (m) |
4.2 |
|
Total Power (kW) |
228 |
|
Max Aggregate Size (mm) |
Gravel |
60 |
Pebble |
80 |
|
Dimension (mm) |
L |
45000 |
W |
17000 |
|
H |
20000 |
|
Total Weight (t) |
100 |
|
Introduction
1. Mixing System: Twin Shaft Concrete Mixer: JS3000 (Capacity: 3000L)
2. Aggregate System: Aggregate batcher: PLD4800
3. Cement System
4. Additive System
5. Air System
6. Weighing System
7. Control System
Quality Control (QC):
1. Third Control
2. ISO9001:2008 Certificate
3. European CE Certificate
4. Enviroment Protection Design
Commercial Terms:
1. Delivery Time : 30-40 Working Days
2. Payment Term : T/T, L/C, etc.
3. Transportation : By Sea or Railway in Container.
After-Sale Service:
1. Turn-Key Solutions
2. Erection & Commissioning Service
3. Operation Training Service
4. Spare Parts Supply ( all working life )
