Hot Sale Screw Type Juicer,apple Juicer
Industrial Fruit Juicer Extracting Machines
1.Brief Introduction of the Fruit juicer
l Application:
ü Fruit :pineapple,apple,pear,mulberry,grape,orange,etc
ü Vegetable:Tomato,ginger,garlic, celery,etc.Different fruit or vegetable has different dealing capacity,the capacity in parameter depends on tomato.
l Features:
ü Spiral forward extrusion
ü Automatically finish the process of milling, extract juice and deslagging
ü Food touching material are made of good quality 304 stainless steel
2.Working Principle of the Fruit juicer
Put the crushed fruit pulp,juic,skin in to feed bin of fruit juice machine,screw become big and big from feed bin to discharge mouth,distance of scew also become small,when material being pressed forward , Spiral cavity become small.Pressed juice flow through filter get the juice barrel,waste residues discharge from the space of screw and taper adjust device.Expand the space ,fruit juice can be more ,but not pure ,decrease the space can get pure juice,you can adjust the space to get the standard fruit juice you want .
3. Prameter of fruit juicer
Model |
Capacity (t/h) |
Power (kw) |
Voltage (v) |
Size (mm) |
OW-0.5 |
0.5 |
1.1 |
380 |
1000x320x1280mm |
OW -1.5 |
1.5 |
4 |
380 |
1560x450x1340mm |
OW -2.5 |
2.5 |
7.5 |
380 |
2200x600x1960mm |
Welcome to contact us about our fruit juicer .
