SINOSUN Bitumen emulsion plant 6T/H
Bitumen emulsion plant is our newly developed bitumen emulsion equipment that has won national patent ( patent No.ZL00226275.4 ). It is designed to produce emulsified asphalt for use in express highway construction and road maintenance projects.
Features of bitumen emulsion plant
- Our bitumen emulsion plant is settled on a foundation, which is convenient to remove and suitable for working is the field. It can be equipped with a water heater of HTF coil heating device to heat the emulsion on the construction site.
- This bitumen emulsion equipment uses an automatic control system to automatically monitor and regulate asphalt content in emulsified asphalt. In addition, it adopts two emulsion tanks to mix the materials and drain water in turn for continuous production. Compressed air drives fluid flow which is governed by the pneumatic valve, thus reducing labor intensity.
- A high efficiency plate heat exchanger is first used to cool the finished emulsified asphalt so as to improve emulsified asphalt storage stability, and then used to heat the cooling water for producing emulsified asphalt, which saves clear water heating expense for lower production cost and makes the process environment friendly and energy saving.
- The rotation speed of the asphalt pump is controlled by a frequency governing motor, and the emulsion flow rate is regulated by a valve ( displayed by the flow meter ). Therefore, asphalt content in emulsified asphalt ( ratio of asphalt to water ) can be accurately and stably controlled.
- HTF heating system is equipped to warm all the pumps before production, which is easy and convenient to replace baking with blowtorch.
- The temperature of HTF heating system and water heating system is automatically controlled.
- All the parts that come into contact with the emulsion are made of qualified stainless steel, which are wear resistant and corrosion resistant, ideal for emulsified asphalt production.
- The emulsion fineness is less than 5μm.
Technical Specifications of bitumen emulsion plant
Model |
RH-6 |
RH-10 |
Remark |
Capacity(T/H) |
6 |
10 |
Rated capacity |
Installation power |
26.5KW |
50KW |
Theory power |
Emulsified fineness |
< 5μm |
< 5μm |
|
Water heating type |
Thermal oil/electric heating |
Thermal oil/electric heating |
|
Blending tank volume |
1.25m3×2 |
1.5m3×2 |
|
Bitumen tank volume |
5 m3 |
6 m3 |
|
Finished product tank |
5 m3 |
6 m3 |
|
Water tank volume |
5 m3 |
6 m3 |
1. Turn-Key Solutions
2. Erection & Commissioning Service
3. Operation Training Service
4. Spare Parts Supply (all working life)
SINOSUN is one of China’s dominant manufacturers and exporters of Precisioned Asphalt Batch Mix Plants and related asphalt batching plant parts.
For over years, SINOSUN has supplied the asphalt industry with high quality asphalt batching plant parts and equipments.
SINOSUN's asphalt solutions including asphalt batching plants are cost effective, user friendly, easy to maintain and strong after - sales services. SINOSUN is equipped with most modern and mature factory setup to produce high quality asphalt batching plant.
Due to the diverse product range and sufficient production capacity, SINOSUN could be able to meet various needs of our customers.
We mainly supply:
1.Stationary asphalt batching plant (SAP series)
2.Mobile asphalt mixing plant ( MAP series)
3.Twin-shaft asphalt mixing plant (QLB series)
4.Twin-drum asphalt mixing plant (SLB series)
5.Continuous asphalt mixing plant (CAP series)
Our asphalt plants have been widely used in home and abroad road construction project, such as Russia, Romania , Poland , Brazil , Philippines , Indonesia etc. In Africa , we have exported to Ethiopia , Angola , Algeria and Libya.
