HUAQIU BJ-22B Diesel Fire Pump With Handle Frame

HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-1
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-2
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-3
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-4
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-5
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame thumbnail-6
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-1
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-2
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-3
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-4
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-5
HUAQIU BJ-22B Diesel Fire Pump With Handle Frame photo-6
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WOQ/HUAQIU
Model Number:
BJ-22B
Contact Supplier Request Quote Chat Now
Zhejiang WOQ Machinery Manufacture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name WOQ/HUAQIU
Model Number BJ-22B



Product Description

HUAQIU BJ-22B diesel fire pump with handle frame is powered by R2V870 diesel engine and the single-level centrifugal pumps of Zhejiang WOQ Machinery Manufacturing Co.,Ltd. It can be self-charge during work. It has feature of compact structure,start convenient,fast water,low fuel consumption,low weight and reliable,so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade,forest fire brigade,towns,rural areas, the mining industry and obligation fire brigade



Technology

HUAQIU BJ-22B diesel fire pump with handle frame techncial data

Appearance dimension

650*610*650mm

Device weight

≤105kg

Max capacity

1500L/min

Pump lift

85m

Out pressure

0.68Mpa

Inlet size

φ80mm

Out size

φ65mm

Dia.of nozzle

φ19mm

Type of inlet

Screw type

Maximum suction depth

7m

Pump priming time

≤20s

Starting way

Electric start

Model of engine

25HP,R2V870

Pump body

Single stage



Detailed Images

HUAQIU BJ-22B diesel fire pump with handle frame pics

HUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frame



Packaging & Shipping

 HUAQIU BJ-22B diesel fire pump with handle frame



Company Information

 HUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frame



Certifications

HUAQIU BJ-22B diesel fire pump with handle frame Certificates

 HUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frameHUAQIU BJ-22B diesel fire pump with handle frame
