Customize segway board 6-Layer Number of Layers fpc assembly pcb
Layers No. |
1-6 layers |
Finished Board Size |
Min.:10x45mm Max.:250x1200mm |
Available Laminates Material |
PI,PET,FR4-PI |
Finished Board Thickness tol. |
±0.01mm |
Finished hole diameter(Min.) |
0.1mm |
Finished hole diameter(Max) |
0.6mm |
NPTH Hole diameter tolerance |
±0.025mm |
PTH hole diameter tolerance |
±0.050mm |
Copper foil thickness |
12um,18um,35um,70um |
Circuit width/spacing(Min.) |
≥0.065mm(1/2oz)≥0.05mm(1/3oz) |
Surface Finished type |
Gold plating,Immersion Gold,Tin plating(lead free),OSP,etc. |
Gold Flash Ni/Au thickness |
Ni:2.54-9um Au:0.025-0.5um |
Immersion Tin thickness |
0.7-1.2um |
Tin plating thickness |
3-15um |
Drill hole position tolerance |
±0.05mm |
Punching dimension tolerance |
±0.05mm |
Certificate |
ROHS,UL,ISO9001 etc |
Feature of touch panel FPC :
1. Flat Flex pcb with different pitch
2. Customize Length
3. Customize Contact: 0.2mm,0.3mm,0.4mm,0.5mm,1.0mm,1.25mm
4. UL Cable & ROHS compliant
Discription of touch panel FPC :
1. Wide Pitch Range: 0.2mm,0.3mm,0.4mm,0.5mm,0.8mm ,1.0mm ,1.25mm,1.27mm, 2.0mm,2.5mm
2. FPC Custom Length: 15mm ~ Longer available
3. FPC Pin Number: 3-100 (custom cable service is provided)
4. FPC Wire Material : UL Style:2896 80C,30V,UL STYLE: 20624 80C,60V
5. All products compliant with ROHS
6. Simplify layout procedure and simplify wiring.
FPC Application:
1.Notebook computers, LCD Display, Optical drive, Hard disk;
2.Printers, Fax machines, Scanners and Sensors;
3.Mobile phone, cell phone batteries, walkie-talkie, mobile phone antenna, mobile phones dual SIM Card, phone cable;
4.All kinds of high-end camera, digital camera, digital camera, DV,
5.VCR magnetic head, laser sensor,CD-ROM,VCD,CD,DVD;
6.Aerospace, satellite/medical equipment, instrumentation, automotive instrumentation;
7.Light bar, LED FPC flashing lights, toys, collar, lamp decoration.
