home use 200KG food elevater dumbwaiter

FOB Price

USD $1,000 - $25,000 / Unit

1 Unit(Min.Order)

Supply Ability 50 Unit / Units per Month
Port home use 200KG food elevater dumbwaiter Shipped on shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China	Brand Name	composed
Model Number	KC	Usage	Other, dumbwaiter
Drive Type	AC	Elevator Type	Goods Elevators

Product Description

Home use 200KG food elevater dumbwaiter

load(kg)	lift size(mm)	well size		door opening	overhead height	windowsill height
load(kg)	lift size(mm)	wid*dep	wid*dep	door opening	overhead height	windowsill height
100	600600800	1100*800	950*650	700*960	3200	700
100	700700800	1200*900	1050*1050	800*960	3200	700
100	800800800	1300*1000	1150*1150	900*960	3200	700
200	900900800	1400*1100	1250*1250	1000*960	3200	700
200	10001000800	1500*1200	1350*1350	1100*960	3200	700
200	8008001000	1300*1000	1200*1200	900*960	2800/3600
200	9009001000	1400*1100	1300*1300	1000*1160	2800/3600
200	100010001000	1500*1200	1400*1400	1100*1160	2800/3600
250	100010001200	1500*1200	1400*1400	1100*1360	3000/4000
300	100010001200	1700*1200	1400*1400	1100*1361	3000/4000
300	100010001200	1500*1200	1400*1500	1100*1362	3000/4000

he main configuration

items	Parts name		brand	producing area	comments
1	Control cabinet	Microcomputer control system	Step	Shanghai	Assembly
		Variable frequency driving	step	Shanghai
		Master contactor	Schneidder	Shanghai(joint venture)
		Relay	Omron	Shanghai(joint venture)
		Air switch	Delixi	Shanghai(joint venture)
		Phase sequence	Ait	Ningbo
2	Tractor	Permanent magnet trction machine	Tongrun	Suzhou	Assembly
2	Tractor	Rotary encoder	Heidenhain	France	Assembly
3	Maneuvering box	maneuvering box panel	Ok	Shanghai
		microcomputer operation panel	Xinshida	Shanghai
		display in the cabin	Xinshida	Shanghai
4	Calling box out cabin	calling board out cabin	OK	Shanghai
4	Calling box out cabin	Display of showing floors	Xinshida	Shanghai
5	Cabin	cabin assembly	Kangchi	Shanghai
5	Cabin	emergency power supply in the cabin	OK	Shanghai
6	Safety parts	speed governor	Olin	Shanghai
		Safety tongs	Letian	Shanghai
		buffer	Lvdun	Shanghai
		light curtain	Weike	Ningbo(joint venture)
7	steel rope		Tianshen	Tianjin
8	Door opener	permanent magnet synchromous motor	Best/Zhanpeng	Shanghai/Zhanpeng
		Frequency converting contro	Best/Zhanpeng	Shanghai/Zhanpeng
		Machine parts	Best/Zhanpeng	Shanghai/Zhanpeng
9	Rail		Hongcheng	Suzhou
10	Rail bracket		Kangchi	Shanghai
11	Traveling cable		Changshun	Shanghai
12	Cabin door		Kangchi	Shanghai
13	Landing door		Kangchi	Shanghai
14	Little door frame		Kangchi	Shanghai

The above is the standard configuration. If you want have a high quality, the configuration can be adjust. But it cannot be lower than the basic configuration.
