WC67Y-40Tx2200 Hydraulic press brake, hydraulic bender,press brake
- 100 Set / Sets per Month
- Shanghai
- T/T
- 10mm hot press brake bending machine for brake pad
- Custom bending press brake and shearing machine
- Square steel tube press brake machine for making gutters
- CNC hydraulic press brake steel bar cutting and bending machine
- Crank type bending machine heavy duty press brake 125t 3200
- 6 axes cnc press brake machine hydraulic for making gutters ceramic
Product Details
Condition: | New | Place of Origin: | Anhui, China | Brand Name: | NFL |
Model Number: | WC67Y | Machine Type: | Press Brake | Raw Material: | Sheet / Plate Rolling |
Material / Metal Processed: | Stainless Steel | Power: | Hydraulic | Automation: | Manual |
Extra Services: | Machining | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hydraulic press brake is main use to bend the plate
The whole structure of the hydraulic press brake:
- Welded structure: the stress of the welded parts can be eliminated by vibration; so this forging press gives high accuracy.
- Frame: consist of right and left wall boards, working table, oil box, slot steel and etc., with high strength
Hydraulic system:
- Adopt integrated hydraulic control system, more reliable
- Consist of motor, oil pump and valve groups
-Be installed at the top of the oil box, which can assure that the cylinder is always full of oil when the slide is moving down at high speed
- Complete working cycle can be realized through the control of hydraulic valve.
- The working pressure at the right side of the wall board can be adjusted by the remote adjustment valve
Advance technology and procedures:
- This metal machining tool is a kind of steel torsion bar synchro press brake.
-Electronic control of back gauges and ram stroke, data displayed and manual setting
| WC67K-200/6000 | WC67K-250/3200 | WC67K-250/4200 | WC67K-250/5000 | WC67K-250/6000 | WC67K-300/4000 | |
Nominal force | kN | 2000 | 2500 | 2500 | 2500 | 2500 | 3000 |
Length of table | mm | 6000 | 3200 | 4200 | 5000 | 6000 | 4000 |
Distance between uprights | mm | 4800 | 2540 | 3140 | 4000 | 5000 | 2900 |
Throat depth | mm | 350 | 400 | 400 | 400 | 400 | 400 |
Ram stroke | mm | 200 | 250 | 250 | 250 | 250 | 250 |
Stroke adjustment | mm | 150 | 180 | 180 | 180 | 180 | 180 |
Max.opening height | mm | 450 | 500 | 500 | 500 | 500 | 535 |
Stokes | Min-1 | ≥3 | ≥3 | ≥3 | ≥3 | ≥3 | ≥3 |
Main motor capacity | kW | 15 | 18.5 | 18.5 | 18.5 | 18.5 | 22 |
Net weight | kg | 23100 | 13900 | 16300 | 19900 | 25100 | 24400 |
Outline dimensions(L×W×H | mm | 6420 | 3840 | 4840 | 5640 | 6420 | 4400 |
WC67K-40/2000 | WC67K-40/2500 | WC67K-63/2500 | WC67K-80/2500 | WC67K-80/3200 | WC67K-80/4000 | WC67K-100/2500 | WC67K-100/3200 | WC67K-100/4000 | ||
Nominal force | kN | 400 | 400 | 630 | 800 | 800 | 800 | 1000 | 1000 | 1000 |
Length of table | mm | 2000 | 2500 | 2500 | 2500 | 3200 | 4000 | 2500 | 3200 | 4000 |
Distance between uprights | mm | 1650 | 2000 | 2000 | 1990 | 2600 | 3350 | 1650 | 2550 | 3350 |
Throat depth | mm | 200 | 200 | 250 | 280 | 280 | 280 | 320 | 320 | 320 |
Ram stroke | mm | 100 | 100 | 100 | 100 | 100 | 100 | 130 | 130 | 130 |
Stroke adjustment | mm | 80 | 80 | 80 | 80 | 80 | 80 | 100 | 100 | 100 |
Max.opening height | mm | 330 | 330 | 340 | 360 | 360 | 360 | 390 | 390 | 390 |
Stokes | Min-1 | ≥11 | ≥11 | ≥10 | ≥10 | ≥10 | ≥10 | ≥10 | ≥10 | ≥10 |
Main motor capacity | kW | 4 | 4 | 5.5 | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 | 7.5 |
Net weight | kg | 3000 | 3600 | 4600 | 5300 | 6400 | 8300 | 7300 | 8200 | 9400 |
Outline dimensions(L×W×H | mm | 2500 | 3000 | 3100 | 3150 | 3820 | 4650 | 3200 | 3790 | 4600 |
