80 Tons C Frame Hydraulic Press/hydraulic Press/hydraulic Press Machine/single Press/eccentric Press/four Column Press
- Shanghai
- T/T
You May Like
-
100 Tons C Frame Hydraulic Press/hydraulic Press/hydraulic Press Machine/single Press/eccentric Press/four Column Press
-
Iron Worker , Ironworker for Metal Works, Steel Worker, Shearing and Punching
-
Steel Iron Worker , Ironworker for Metal Works, Steel Worker, Shearing and Punching
-
Hydraulic Iron Worker Q35Y Series
-
Q35 Metal Steel Hydraulic Iron Worker
-
Steel Iron Worker Hydraulic Iron Worker
Product Details
| Place of Origin | Anhui, China | Brand Name | NFL | |
| Model Number | Y41 |
Product Description
Specifications
1.High precision,Wide application2.EU CE Certification
3.CQC,ISO9001:2008
4.High performance,
5.Easy to operation.
Y41 Series C Frame Hydraulic press is main use to make the shape or the other usages.
The main technical parameters of Y41 hydraulic press as belows:
the capacity is from 1T to 315T
type | Unit | 1T | 2.5T | 6.3T | 10T | 16T | 25T | 40T | 63T | |
Nominal force | KN | 10 | 25 | 63 | 100 | 160 | 250 | 400 | 630 | |
The maximun working pressure of the fluid | MPa | 4.5 | 4.5 | 5.1 | 5.8 | 13 | 20.5 | 23 | 18.5 | |
The maximum open height | mm | 300 | 300 | 450 | 500 | 550 | 600 | 700 | 800 | |
The maximum stroke of the slipper | mm | 120 | 160 | 250 | 300 | 350 | 350 | 400 | 500 | |
Slippe speed | Down velocity of the slipper | mm/s | 60 | 60 | 85 | 85 | 110 | 110 | 85 | 85 |
The working velocity of the slipper | mm/s | 7-15adjustable | ||||||||
Return velocity of the slipper | mm/s | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 | |
Throat depth | mm | 100 | 160 | 250 | 250 | 280 | 280 | 300 | 300 | |
The size of the working platform | Front,Rear | mm | 300 | 300 | 420 | 420 | 500 | 500 | 550 | 580 |
Left,Right | mm | 400 | 400 | 450 | 450 | 550 | 600 | 600 | 600 | |
The height of the working platform to the surface of the floor | mm | 730 | 730 | 730 | 730 | 730 | 730 | 730 | 730 | |
The size for the cutting hole | mm | 70 | 70 | 80 | 80 | 100 | 100 | 100 | 100 | |
The power for motors | kw | 1.1 | 2.2 | 2.2 | 3 | 5.5 | 5.5 | 5.5 | 7.5 | |
The configuration size of the machine tool | Front,Rear | mm | 530 | 730 | 1000 | 1100 | 1150 | 1200 | 1200 | 1550 |
Left,Right | mm | 500 | 550 | 730 | 800 | 800 | 830 | 900 | 1050 | |
The height above the floor | mm | 1455 | 1600 | 1800 | 1900 | 2100 | 2300 | 2400 | 2680 | |
Total weight | ||||||||||
