Fiber Optical Plastic Fiber Distribution Box

SDB008/016

Features

Can accommodate 1*4, 1*8 & 1*16 PLC splitter

Ultra violet resistant and weather proof

Up to 16 FTTH drops.

Wall and pole mountable

2 inlet ports (for cables with max diameter 12mm), 16 outlet ports

Protection class: IP 67

ROHS compliance

Application

FTTH access networks

CATV networks

Data communications Networks

Local Area Networks

Specification

SDB032

Used for wall mount installation

Can accommodate 1*8, 1*16 & 1*32 PLC splitter module

2 inlet ports and 2 outlet ports

PC material with excellent waterproof function

SDB032A

Used for wall mount installation

Can accommodate 1*8, 1*16 & 1*32 PLC splitter module

2 inlet ports and 8 outlet ports

Cold rolled steel material

SDB064

Description:

This product is applicable to use in FTTH project which is used after fiber optic cable to the building, installing in the corridor, basement, room and building’s outer walls. It may distribute cable after installed splitters. It also may draw out room fiber optic cables by direct or cross-connections. It is with the functions of mechanical splice, fusion splice, light splitting, wiring distributions.

Features

It is adopted high-quality cold rollrd steel, electrostatic spraying outdoor water proof powder.

Door lock is use of high quality outdoor water proof lock, wall mounted cabinet.

Operating temperature:-30°C~+55°C,storage temperature:-40°C~+60°C.

Box provides access to two 12 cores fiber optic cable and access up to 64 pieces of customer cables. It is also matching multi fiber optic cable access.

Can fit for 2pcs 1*32 PLC splitters (the dimension of the PLC module is no bigger than 120mm * 80mm * 18mm)

Can install 72pcs SC & FC adaptors, easy for operation and maintenance
