Help CenterCrossover Stereo 2-way / Mono 3-way 266XL
Related Products
Specifications
1 goof proof operation to smooth uneven levels,add sustain to guitars,fatten drums or tighten up mixes.Goof proof operation to smooth uneven levels, add sustain to guitars, fatten drums or tighten up mixes
New gate timing algorithms ensure the smoothest release characteristics
Program-adaptive expander/gates
Great sounding dynamics control for any type of program material
Separate precision LED displays for gain reduction, compression threshold and gate threshold allow quick, accurate setup Stereo or dual-mode operation
Balanced inputs and outputs on 1/4" TRS and XLR
Side Chain insert
Classic "Auto" mode
FREQUENCY RESPONSE
Flat: 20Hz-20kHz, +0, -0.5dB
Bandwidth: 0.35Hz-80kHz, +0, -3dB
Input Impedance: 40kΩ Balanced/Unbalanced
Max Level: +22dBu
OUTPUT
Impedance: Balanced +4dBu: Balanced: 200Ω,
Unbalanced: 100Ω
Max Level: +21dBu into 600Ω
SIDECHAIN INSERT
Input Impedance: >10kΩ
Output Impedance: ≤2kΩ
Max Level: +21dBu
Distortion +Noise: <0.2% any amount of compression at 1kHz
SYSTEM PERFORMANC Intermodulation
Distortion: <0.2% SMPTE
Noise: <-93dBu unweighted
Dynamic Range: >114dB, unweighted
Crosstalk: <-93dB @ 1kHz
Common Mode Rejection: >40dB (Any Frequency) Stereo Coupling: True RMS Power Summing?
Threshold Chracteristics: Selectable OverEasy? or hard knee
Exp/Gate: Program Dependent Threshold
Compressor: -40 to +20dB Expander/Gate: -60 to + 10 dB
Ratio: Compressor: 1:1 to ∞:1 Expander/Gate 1:1 to 4:1
ATTACK TIME
Compressor: Scalable Program Dependent
Expander/Gate: <100 μsec
RELEASE TIME Compressor: Scalable Program Dependent
Expander/Gate: Program Depenedent
PHYSICAL
Dimensions: (H x W x D) 1.75"x5.75"x19" (4.45cm x14.6cm x48.5cm)
Weight: Net Weight: 5 lbs. (2.3 kg);
Shipping weight: 7 lbs (3.2 kg)
