Specifications
with hydraulic system to control the cutting speed,variable speeduseful guide system,to keel the blade can be use with long
This Double-Column & Double-Cylinder Horizontal Band Sawing Machine is designed and
manufactured independently by our company. It's combination of mechanism, electrics
and hydraulic system. It's the sawing and cutting equipment of heavy-duty
or medium-duty with high productivity.
Features:Chromized treatment on surface of column that are uniform in size; synchronous double
cylinders for lift and drop of saw beam, so constant in sawing performance;
hydraulic or manual way optional for holding the work-piece; both front and rear
vice clamps for fastening work-piece and saw blade running inside; adjustable
tungsten-steel block as the direction guide that guarantees the sawing precision;
easy to operate, narrow in kerf, material and energy-saving, scientific in structure,
nice in look, and high in productivity
ITEM |
UNIT |
MODEL NO. |
||
GT4220A |
GT4228 |
GT4235 |
||
Cutting capacity |
mm |
200 200X200 |
280 280X280 |
350 350X350 |
Blade speed |
m/min |
3 steps 27/45/69 |
3 steps 27/45/69 |
3 steps 27/45/69 |
Feed speed adjust |
-- |
Hydraulic stepless variable speed |
Hydraulic stepless variable speed |
Hydraulic stepless variable speed |
Blade size |
mm |
2800X27X0.9 |
3505 X 34 X 1.1 |
4115 X 34 X 1.1 |
Clamping type |
-- |
Hydraulic |
Hydraulic |
Hydraulic |
Main motor power |
kw |
1.5 |
2.2 |
3 |
Oil pump motor power |
kw |
0.44 |
0.44 |
0.44 |
Main drive reduce speeds type |
-- |
worm |
worm |
worm |
Overall dimensions |
mm |
1400X900X1100 |
1860 X 900 X 1200 |
2000X1000X1500 |
Weight |
kg |
380 |
550 |
900 |
