double grider overhead outrigger pad , UHMWPE and HDPE crane let support pads

 Outrigger pad is made of UHMWPE or HDPE material . Because UHMWPE and HDPE material has the following advantage :

• Apply the Right material for your application
• good tensile strength
• good impact intensity
• super compression strength
• good breaking elongation
• 15 Percent the weight of steel pads
• Chemically inert, serviceable from 180° F to - 250° F
• Corrosion, chemical, wear and moisture resistant.
• Non-stick surface, easy to clean.
• Compressive loads up to one million pounds
• Up to 15,000 pounds per square foot

 Application of our products

Transportation machinery: Guide rail, convey belt, convey device slide block seat, fixing board, product flow line timing star wheel

Food processing machinery: With its performance of high wear resistance, antiimpact resistance, inadhesion resistance, nontoxic and clean property, UHMWPE material can be used in planet wheel, bottle convey counting bolt, filler bearing, bottle holder parts, washer guide bolts, air cylinder, gear, roller cone, chain wheel handle, which is easycleaning, longenduring, and anti-mildew.

Paper making machinery: With its performance of high wear resistance and good selflubrication, UHMWPE material can be used in water suction tank cover, skew guide wheels,scrapper , bearing, nozzle, filter, oil tank, friction bar, felt cleaner.

Textile machinery: With its performance of highwear resistance, antiimpact and good selflubrication, UHMWPE material can be used in scutcher, shock absorber shield, contactor, crankshaft connecting rod, picker stick, skew rod shaft sleeve, swing rear beam.

Construction machinery/agriculture machinery: Bulldozer blade lining. Dumper ripper lining, tractor plow inner lining.

Chemical machinery: Valve, pump, washer, filter, gear, nuts, seal rings, nozzle, plug, shaft sleeve, thread pipe.

Port machinery/ship machinery: Ship parts, suspension bridge side roller, friction block.

Ordinary machinery: All types of gear, bushing, liner, sliding plate, clutch, guiding unit, brake, hinge, flexible coupler, roller, bearing wheel, fastening unit, platform sliding unit.

Dyeing decor: Dip dyeing machine bearing, scrapper, sliding plate, lining washer, seal, framing guide disc,

Culture and sport products: Snow dip liner, powered sledge, skating rink paver, ice field protection frame.

Healthcare products: Shape righting surgery, artificial joint, artificial limb.

Other: Cooling machine, nuclear power plant shield, electric galvanized parts, and ultralow temperature machine parts.Mostly using of its high-wear resistance, high anti-impact resistance, anti-cold resistance, self-lubrication.

Size of outrigger pads

Length(mm)               Width(mm)            Thickness(mm)

400                                400                    40 ,50, 60,70,-----150mm

500                                500                    40 ,50, 60,70,-----150mm

600                               600                      40 ,50, 60,70,-----150mm

700                               700                      40 ,50, 60,70,-----150mm

- -                                                                40 ,50, 60,70,-----150mm

1500                            1500                      40 ,50, 60,70,-----150mm

1600                           1600                       40 ,50, 60,70,-----150mm

2000                           2000                        40 ,50, 60,70,-----150mm

Our UHMW-PE outrigger pads standard sizes:

1.Thickness: 6 - 300mm
2. Width: max 2000mm
3. Normal standard size:

Any small size need us to cut , we can satisfy your special need

The properties of UHMW-PE Sheet

Property                                                            Unit                                         Value

 Density                                                          g/cm3                                     0.93-0.96

 Average molecular weight                         g/mol                                3million- 10 million

Tensile strength (23°C in air)                        MPa                                          22

 Breaking strength                                           MPa                                          42

 Tensile strain at break                                     %                                              600

 Charpy impact strength (notched)             mJ/mm2                                 No break

 Ball indentation hardness                             N/mm2                                     42

 Shore D hardness                                                  --                                     65-70

 Abrasion                                                                 %                              70-80, steel = 100

 Static Friction Coefficient                                    --                                      ≤0.16

 Kinetic Friction Coefficient                                 --                                       ≤0.10

 Water Absorption                                                --                                            NIL

 Elongation at break at 23 degress                   %                                      ≥300

 Temperature resistance                                       °C                                 -269 to +85

 Melt Temperature                                                  °C                                   130-140

Benefits:

Work in sub zero temperatures
Easy to mount, replace
Reduced downtime.
Lower maintenance costs.
Cost Efficient compared to Steel or Aluminum

     Established in 1998,Tangyin Huaxiang Plastic Industry Co.,Ltd. is one of the largest Engineering Plastic products manufacture in China.All the stuff in our company are dedicated to producing satisfying products and developing new products for our customer.

Basic Information

Product/Service (We Sell): uhmw pe sheet,uhmw pe pad,UHMWPE Fender Pad,UHMWPE outrigger pad,UHMWPE Dock bumepr

Number of Employees: 101 - 200 People

Factory Information

Factory Size (ters): 3,000-5,000 square meters

Factory Location: Liaohe Road,Ningjin Industry zone,Shandong,China

Number of Production Lines: Above 10

Number of R&D Staff: 5 - 10 People

Number of QC Staff: 5 - 10 People

Management Certification: ISO9001

Contract Manufacturing: OEM Service Offered Design Service Offered Buyer Label Offered
