PCBA manufacturing, electronics pcb assembly supplier
Electronic PCBA PCB Full assembly capability
| 1 | layer | 1-10layer |
| 2 | Material | FR4, FR1,FR2,Aluminum |
| 3 | Board Thickness | 0.2-5mm |
| 4 | Max.finished board side | 500mm*560mm |
| 5 | Min.drilled hole size | 0.012mm |
| 6 | Min.line width | 0.0120mm(3mil) |
| 7 | Min.line spaceing | 0.0120mm(3mil) |
| 8 | Surface finish/treatment | HASL/HASL lead free,Immersion gold Inmersion Silver/Gold.Osp.Gold Plating |
| 9 | Copper thickness | 0.5-4.0oz |
| 10 | Solder mask color | Green/Black/White/Red/Blue/Yellow |
| 11 | Inner Packing | Vacuum packing Plastic bag |
| 12 | Outer packing | Standard carton packing |
| 13 | Hole tolerance | PTH:±0.076,NTPH:±0.05 |
| 14 | Certificate | UL,ISO9001,ISO14000,ROHS |
| 15 | Profiling punching | Routing,V-CUT,Beveling |
| 16 | Assembly service | Providing OEM service to all sorts of printed circuit board assembly |
| 17 | Open / Short testing | Yes |
Packaging
Items per Carton: 50 Pieces/Carton
Gross Weight: 15.0KG
Package Type: 1pcs/ESD bubble bags K=K Honey carton box
Please keep reading the following about our services
- PCB Layout Design and Assembly
- PCB Assembly
- electronic Product OEM/ODM
- Mobile Power bank
- ID Design
- Mechanic Design
- Packing Design
- Final Product Assembly
Manufacturing capability
- PCBA Size: 457x567cm(max);4x3cm(Min)
- IC Pitch(min):0.2mm
- Chip Size(min):0402 /1005(1.0x0.5mm)
- BGA Size:8x6mm~37x37mm
- BGA Pin Count: 48pin~600pin
- Package: SOP/SSOP/PLCC/QFP/QFN/BGA/FBGA/u-BGA
- u-BGA Ball diameter: 0.2mm
Main Markets
-Domestic Market
-Western Europe
-Eastern Asia
-Mid East
-Oceania
-Africa
-Southeast Asia
-Eastern Europe
-South America
-North America
Production line:
Trade Term:
1. Payment: T/T, LC,DA,DP,Paypal.
2. Lead time: 10 working days for normal products(components less than 100pcs on pcb board).
3. Samples can be available within 8~10working days
4. Shipping freight is quoted under your requests
5. Shipping port: Shenzhen or HongKong
