Features
Our Electric fire truck has following features:
- Aluminum box and rolling door as rear box, laminated glass
- Front independent suspension, helix spring and shock absorber
- Digital meter with headlights, turn signals, fog lights, taillights and so on
- Radio and MP3 adaptor, optional CD player
- Four wheel hydraulic drum brake and foot parking brake
- Curtis controller and Trojan Battery are imported from US manufacturer directly
Application
Our Electric fire truck can be used in many places.
- Resort
- Hotel
- Theme Park
- Amusement Park
- Residential Community
- Campus
- Station, Port
- Any place where a fire fighting vehicle is needed
| Model and description | EG6010F, electric mini fire fighting car |
| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power | 3.8KW DC/5KW AC |
| Controller | Curtis brand, Series excited/AC, imported |
| Passenger capacity | 4 |
| Range (loaded) based on flat road at a speed of 20km/h (km) | >65 and 80 |
| Max. speed(km/h) | 25/40 |
| Minimum turning radius (m) | 4 |
| Max. climbing ability | 20% |
| Max. loading weight | 500kgs |
| Overall dimensions (mm) | 3950X1400X2010 |
| Rear box dimensions(mm) | 850X1120X1100 |
| Ground Clearance (mm) | 140 |
| Body and Frame | |
| Frame | Welded steel framework with sand blasting+paint treatment |
| Body | Fibreglass |
| Roof | FRP |
| Windshield | Laminated |
| Rear box | Aluminum box + rolling door |
| Large Seats: | Sponge + artificial leather |
| Floor | Bamboo board+ rubber |
| Electric system | |
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 rear turn signals and 2 rear brake lights, with DC-DC converter (converting from 48V to 12V), horn. |
| Dashboard meter | current meter, battery power meter, speedometer |
| Audio system | Tape player with radio (12v)(including 2 water-proof speakers, wired microphone) |
| Charger | input 110V-240V~50Hz-60Hz, output 48V, 25A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker rocker compensating function |
| Brake system | 4-wheel hydraulic brake + foot activated parking brake |
| Drive mode | Rear axle two stage deceleration, motor direct driving |
| Front Suspension system | Independent suspension, helix spring + shock absorber |
| Rear Suspension system | rear plate spring + shock absorber |
| Wheel & Tyre | 20.5x8.0-10 tire, 6J-10 steel wheel, wheel cap |
| Color | |
| Body Color | Fire red |
| Seat Color | Black |
| Others | |
| Provides various options like: CD player, seatbelt, various fire fighting tools, equipments like fire clothing, wrentch, helmet, gloves, boots,flashlights etc.. | |
We provide many color options to our Electric fire truck, customized color is available with extra cost.
| Item | Pure white | Pure black | Red |
|
Body (exclude roof) |
|
||
| Metallic green | Champagne | Navy blue | |
| |||
Our main products category includes
| Electric Golf Cart | Electric Golf People Mover | Electric Utility Vehicle |
| Electric sightseeing bus (shuttle bus) | Electric Personal Carrier | Electric Hunting buggy (Lifted Car) |
| Electric Industrial Truck | Electric Garbage Truck | Electric Fire Truck |
| Electric Hotel/Resort Car | Electric Classic Car | Other Special Vehicle |
- One of the first movers of low speed 4 wheel electric vehicles business in China;
- Private company with capital of USD16,000,000.00;
- Founded in 1999 with more than 400 employees including more than 70 engineers;
- ISO9001, IS14001, SGS, WMI certified;
- Annual sales volume of more than 10,000 to more than 80 countries around the world;
- 20,000 square meters workshop with 3 production lines
Find some photos below for your reference! You can view our Company Profile for more information!
Suzhou Eagle has passed and got the certificates of ISO9001-2008 for quality management system and ISO14001-2004 for environmental management system.This golf cart has pass CE (EMC) test.
1. What is your lead time for production?
The typical lead time of our vehicles is 2-3 weeks.
2. What kind of warranty Eagle provides?
We provide 13 months warranty to the vehicles sold from the shipping date. At the same time, we will provide some FOC spare parts for rapid worn parts.
3. What kind of payment methods can you accept?
Normally we can accept T/T and L/C at sight.
4. What is your MOQ?
We do not have MOQ request. You can order just 1 sample car. However, additional packing and operating cost will be charged if delivered in LCL way.
5. Can I put my own Logo on the vehicles?
Yes, you can put your own Logo on the vehicles.
6. Do you provide OEM service?
Yes, we do provide OEM service. However, we will require minimum 500 units vehicles yearly for OEM project.
7. Can you customize the vehicles according to our special request?
Yes, we can customize the vehicles according to your request unless the customization is not related to the chassis and mold of any parts.
8. Do you supply spare parts if I buy your vehicles?
Yes, we supply all the spare parts used in our vehicles at reasonable price and lead time. Furthermore, for the model which we stopped production, we even supply spare parts in 5 years from the year we stopped it.
9. Do you provide after service if I buy your vehicles?
We will provide spare parts and technical support for after service. However, if any parts need to replace, you will need to do this yourselves, we will provide instruction if needed.
10. Do you provide spare parts book and operational manual?
Yes, we provide them. The operational manual will be sent together with the vehicles. The spare parts book will be sent via email separately.
11. What is the order procedure?
The typical order procedure is as following.
You send us the PO with all your request;
We send you back the International Sales Contract, Sales Confirmation and Proformal Invoice ;
You signed back the International Sales Contract and Sales Confirmation;
You arrange the down payment or issue the L/C (send us the draft first for confirmation before original one is issued);
We arrange the production after receive the down payment or original L/C;
We book the space according to the estimated finish date of the vehicles;
You arrange the balance payment before container loading if the payment term is T/T in advance;
We send you the shipping documents after shipping date;
You arrange the balance payment if the payment term is L/C at sight.
12 Do you provide Trade Assurance via Alibaba?
Yes, we do. Trade Assurance order is welcomed!
