Features
Our 29 seats electric bus train has following features:
- Independent suspension, helix spring and shock absorber; rear plate spring + shock absorber
- Digital meter with headlights, fog lights, turn signals, taillights and so on
- Radio and MP3 receiver, optional CD player to replace MP3 receiver with 4 pcs speakers
- Front wheel hydraulic drum brake and hand parking brake
- Curtis controller and Trojan Battery are imported from US manufacturer directly
Application
Our 29 seats electric bus train can be used in many places.
- Resort
- Theme Park
- Amusement Park
- Residential Community
- Campus
- Station, Port
- Any place where a green, quiet and cost effective vehicle is needed
| Specifications | Model | EG6158T+EG6158T trailer ( 29 seater electric bus train ) |
| Key Components | Power Source | Pure Electric |
| Electric System | Only DC system is available | |
| Battery | Trojan battery | |
| Motor | Chinese Motor | |
| Controller | Curtis controller | |
| Charger | China origin, input 110V-240V~50Hz-60Hz, | |
| Performance | Passenger capacity | 14+15 |
| Range (loaded) based on flat road at a speed of 20km/h (km)* | Up to 78 | |
| Max. speed | Up to 40 | |
| Minimum turning radius (m) | 9 | |
| Max. climbing ability (loaded) | Up to10% | |
| Max. movement after brake at speed of 20km/h | ≤N/A | |
| Max. loading weight | 2000kgs | |
| Dimensions | Overall dimensions (mm) | 2pcs, 5000x1490x2050 |
| Min. ground clearance (mm) | 135 | |
| Wheelbase (mm) | 2710 | |
| Front wheel tread (mm) | 1222 | |
| Rear wheel tread (mm) | 1185 | |
| Body and Frame | Frame | Welded steel framework with sand blasting+paint treatment |
| Body | Fibreglass(the first seat bottom and dashboard), PP(other seat bottoms and front body) | |
| Roof | Fibreglass+aluminum frame, with roof handle | |
| Electric system | Lighting system and horn | Headlights,front turn signals, fog lights, rear turn signals, taillights,fog light, 1 reverse light, with DC-DC converter, horn. |
| Steering and Suspension | Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | Four wheel hydraulic drum brake+hand parking brake | |
| Suspension system | Front suspension:Independent suspension, helix spring + shock absorber;Rear suspension:rear plate spring + shock absorber | |
| Driving mode | Clutch, 5F+1R gear box, transmission shaft | |
| Rear axle | Integrated | |
| Wheel & Tyre | 4J*12 Steel wheel, wheel cap, 155R12,8PR | |
| Options | 2point seat belt | |
| Overshadowing Curtain/Enclosure | ||
| New seat | ||
| Formed seat&backrest vinyl | ||
| Inner rear view mirror | ||
| License plate light | ||
| CD player to replace MP3 receiver | ||
| Microphone Wired | ||
| with water sprayer | ||
| Solar panel | ||
| On-board charger | ||
| Right hand drive system | ||
| Electrical power steering | ||
| 4J*12 Aluminum wheel, | ||
| Body Color | Up to 6 kinds of standard color for option | |
| Loading | Both Assembly and Disassembly are available | |
We provide many color options to our 29 seats electric bus train, customized color is available with extra cost.
| Item | Pure white | Pure black | Red |
|
Body (exclude roof) |
|
||
| Metallic green | Champagne | Navy blue | |
| |||
29 seats electric bus trainwill be packed in steel crate
| Container loading qty | Assembled | Disassembled |
| Qty/20' | / | 1 |
| Qty/40' | 1units | 2 |
| Qty/40'HQ | 1units | 2 |
Our main products category includes
| Electric Golf Cart | Electric Golf People Mover | Electric Utility Vehicle |
| Electric sightseeing bus (shuttle bus) | Electric Personal Carrier | Electric Hunting buggy (Lifted Car) |
| Electric Industrial Truck | Electric Garbage Truck | Electric Fire Truck |
| Electric Hotel/Resort Car | Electric Classic Car | Other Special Vehicle |
- One of the first movers of low speed 4 wheel electric vehicles business in China;
- Private company with capital of USD16,000,000.00;
- Founded in 1999 with more than 400 employees including more than 70 engineers;
- ISO9001, IS14001, SGS, WMI certified;
- Annual sales volume of more than 10,000 to more than 80 countries around the world;
- 20,000 square meters workshop with 3 production lines
Find some photos below for your reference! You can view our Company Profile for more information!
Suzhou Eagle has passed and got the certificates of ISO9001-2008 for quality management system and ISO14001-2004 for environmental management system.This golf cart has pass CE (EMC) test.
1. What is your lead time for production?
The typical lead time of our vehicles is 2-3 weeks.
2. What kind of warranty Eagle provides?
We provide 13 months warranty to the vehicles sold from the shipping date. At the same time, we will provide some FOC spare parts for rapid worn parts.
3. What kind of payment methods can you accept?
Normally we can accept T/T and L/C at sight.
4. What is your MOQ?
We do not have MOQ request. You can order just 1 sample car. However, additional packing and operating cost will be charged if delivered in LCL way.
5. Can I put my own Logo on the vehicles?
Yes, you can put your own Logo on the vehicles.
6. Do you provide OEM service?
Yes, we do provide OEM service. However, we will require minimum 500 units vehicles yearly for OEM project.
7. Can you customize the vehicles according to our special request?
Yes, we can customize the vehicles according to your request unless the customization is not related to the chassis and mold of any parts.
8. Do you supply spare parts if I buy your vehicles?
Yes, we supply all the spare parts used in our vehicles at reasonable price and lead time. Furthermore, for the model which we stopped production, we even supply spare parts in 5 years from the year we stopped it.
9. Do you provide after service if I buy your vehicles?
We will provide spare parts and technical support for after service. However, if any parts need to replace, you will need to do this yourselves, we will provide instruction if needed.
10. Do you provide spare parts book and operational manual?
Yes, we provide them. The operational manual will be sent together with the vehicles. The spare parts book will be sent via email separately.
11. What is the order procedure?
The typical order procedure is as following.
You send us the PO with all your request;
We send you back the International Sales Contract, Sales Confirmation and Proformal Invoice ;
You signed back the International Sales Contract and Sales Confirmation;
You arrange the down payment or issue the L/C (send us the draft first for confirmation before original one is issued);
We arrange the production after receive the down payment or original L/C;
We book the space according to the estimated finish date of the vehicles;
You arrange the balance payment before container loading if the payment term is T/T in advance;
We send you the shipping documents after shipping date;
You arrange the balance payment if the payment term is L/C at sight.
12 Do you provide Trade Assurance via Alibaba?
Yes, we do. Trade Assurance order is welcomed!
