Help CenterHigh Quality Forklift Parts of Curtis Motor Controller 1207-4102 (24V /250A )
Related Products
-
High Quality Forklift Parts Curtis 24V dc Controller 1207-5101US$ 1 - 300MOQ: 1 Piece -
High Quality Forklift Parts Curtis Electric Motor Controller 1243-4220 (24-36V)US$ 100 - 250MOQ: 1 Piece
-
High Quality Forklift Parts Curtis AC Motor Controller 1230-2402 (24V 200A)US$ 1 - 300MOQ: 1 Piece
-
Forklift Parts Curtis ac Walking Controller 1230-2405 (24V)NegotiableMOQ: 1 Piece
-
High Quality Forklift Parts TCM Drive Module N61F30845A/B/DNegotiableMOQ: 1 Piece
1,Product information:
Curtis PMC 1207B series motor speed controllers are the direct replacements for the earlier 1207A models. They feature a microprocessor based logic section combined with a proven MOSFET power section. The 1207B series controllers are efficient, cost effective and easy to install.
APPLICATION
The Curtis PMC 1207B controllers are ideally suited for small electric vehicle applications, such as walkie fork/pallet trucks, mini personnel carriers, sweepers, and other small series or compound motor applications.
er MOSFETs provides high efficiency, silent operation and reduced motor and battery losses.
• Thermal protection and compensation circuitry provide under temperature cutback, constant current limit over the operating range and linear rollback in over temperature. No sudden loss of power under any thermal conditions.
• Power connections made by solid copper busses with polarized Molex connector for control signals.
• Compact size.
• Over voltage and under voltage protection.
• Fully compatible with Curtis PC software tools and hand held programmers for full parametric adjustment, tuning, test and diagnostics.
• Complete diagnostics of the controller can also be accomplished with the built-in status LED.
• Meets or exceeds EEC fault detection requirements with circuitry and software to detect faults in the throttle circuit, MOSFET drive circuits, MOSFET transistors, contactor drivers and contactors.
• Input sequencing options include neutral start (HPD) and static return to off (SRO).
• True arcless contactor switching with microprocessor controlled contactor sequencing.
• Throttle position variable or fixed plugging current options.
• Neutral braking option provides for automatic plug braking in neutral.
• MultiMode™ option for programmable two mode (current limit, speed, acceleration) operation.
• Emergency reverse function (belly button) provides full function with a single input. Additional output provides for an emergency reverse circuit continuity check.
• Anti-rollback (ramp start) function gives full power for starting on ramps.
• Simple contactor and switch wiring. Coil drivers are monitored for short and open circuit for fail-safe operation.
• Flexible throttle circuitry accepts a variety of throttle types including: 5k–0, 0–5k, 0–5v, and three wire potentiometer.
• Programmable output for use as either a main contactor driver or a shunt field driver.
2,Package :
Normally we use the standard exporting packaging , we also can according to clients' request .
3,Company profile :
Hefei Huanke Forklift Parts Co., Ltd, is a professional supplier of spare parts in China. Our company specializes in various kinds of pallet truck parts and forklift parts for both domestic and international markets.
Our product category covers forklift control system, running system, drive system, hydraulic system etc. Controller, contactor, sensor, PU wheel and other parts are supplied by our Huanke company. Meanwhile, we have set up purchase department and development department to supply different brands of superior pallet truck parts and forklift parts, such as, TCM, TOYOTA, NICHIYU, NISSAN, MITSUBISHI, LINDE, HYSTER, DAEWOO, TAILIFT, HELI, HANGCHA, JAC, BAOLI etc.
