Hot sale 12v forklift hourmeter 803
- 1000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
- Hand tool parts castings
- OEM/ODM steel air tool parts / needle bar bushing
- air chuck,air accessory,pneumatic tool parts
- Air conditioner parts develop stamping tooling die
- Investment Casting Pneumatic tools accessories with Stainless Steel and Alloy Steel Materials
- customized high quality Milling Tools
Product Details
Place of Origin: | Anhui, China | Brand Name: | Huanke | Model Number: | 803 |
Product Description
Battery indicator 803R
803 combines in one instrument a completely solid state battery discharge indicator,an LCD hour meter and lift lockout,housed in a 52mm,case. Void of moving parts,this combination instrument is exceptionally reliable even in severe operation environments.
Application
Model 803 is a combination gauge ideally suited for electrically powered vehicles.
Features
Fuel Gauge Features
Multicolor 10-bar LED displays state of charge (5 green,3 yellow,2 red LEDs).
Flashing red LED signals "enery reserse" alarm at 70% discharged.
Double flashing red LEDs signal "empty" alarm at 80% discharged.
Normally closed relay opens at 80% discharge for lift lockout.This unique holding relay will only lock out at the end of a lift cycle.
Recognizes improperly charged battery.
Keyswitch activated LED display(Fuel gauge electronics are energized)as long as they remain connected to the battery).
Wide range adjustable discharge profile.
Dual reset methods in each gauge:Open Circuit Reset for vehicles that exchage batteries and Charge Tracking Reset for vehicles whose batteries remain connected to the gauge during recharge.
Hour Meter Feature
Monitors use-time throughout the equipment's lifespan.
Records and displays up to 99,999.9 hour on its LCD,rolls over and continues to count and display.
Hour meter LCD remains on as long as battery is connected.
Stores latest total in EEPROM nonvolatile memory,without need of power.
Operates and displays in temperatures from -40℃ to +65℃ under harsh conditions of vibration,shock,moiture and dust.
System Voltage
Avaiable in single voltages from 12 VDC to 80 VDC,or in dual voltage of 24/36,36/48,24/48 or 72/80 VDC.Operating range is ± 25% of nominal voltage.
