Cylinder Mold for 3200 Model Paper Machine

Name: Cylinder Mold for 3200 Model Paper Machine
Brand: Dingchen
SKU: 103020977
Availability: InStock

Zhengzhou Dingchen Machinery Co., Ltd.

5Yrs

Cylinder Mold for 3200 Model Paper Machine thumbnail-1

Cylinder Mold for 3200 Model Paper Machine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Henan, China

Brand Name:

Dingchen

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Henan, China

Brand Name Dingchen

Specifications

Paper making cylinder mould
1 Specification: Dia1000Dia1250Dia1500Dia1800Dia2000
2 Working face range: 1000-5000mm

Paper cylinder mould
Specification: Dia1000Dia1250Dia1500Dia1800Dia2000

Working face range: 1000-5000mm

Main character: Improve water filter area and speed, increase the capacity.

1500mm cylinder mould technical data:
1/Diameter 1500mm
2/Face length 2000mm
3/Diameter of SS stick 12mm
4/Qty of SS stick 80
5/Qty of middle supportchip 14 PCS
6/Thickness of SS strip 15mm
7/Diameter of axis 180mm
8/Bearing model 113624
9/Stainless steel winding scrip δ = 1.5 × 25mm
10/Outer arm of wheel made by cast iron
11/Inner arm of wheel made by cast iron
12/Pull rod Q235A 3sets
13/Axle: It is made byΦ 180mm seamless steel pipe. Wall thickness is 14mm.

The material of spindle nose is carbon steel., thermal refining.
14/Technical requirement: Surface polishing, winding scrip chamfering, knurl treatment,

straightness of oversheet≤ 0.025mm/m, static equilibrium. 17/Dimension: 1.6mx1.6mx2.4m
18/weight: 1ton per set.

...
