DTK3205B Bi-directional Laser Automatic Barcode Reader

DTK3205B Bi-directional Laser Automatic Barcode Reader photo-1
Negotiable MOQ: 1 Pint (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Other, Business Card Scanner, Stand
Scan Element Type:
Other, Laser
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Products Status Stock
Type Other, Business Card Scanner, Stand
Scan Element Type Other, Laser
Interface Type USB
Optical Resolution 0.1mm
Scan Speed 100 scans/se
Brand Name detaik
Model Number DTK3205B
Place of Origin Guangdong, China

Specifications

Automatic laser barcode scanner
Scanner type:laser
Stand mode:stand
Directly made by factory
Cheap price

DTK3205B LASER BARCODE READER



Optical

Scanner Type

Bi-directional

Light Source

65- 670nm(visible)

Scan Rate

100 scans per second

Scan type

Automatic scanning

Resolution

0.10mm (4mil) PCS0.9

Reading Distance

2.5 - 600mm (100% UPC/EAN)

Print Contrast

30% minimum reflective difference

Dimensions

L172.mm × W77mm × H72mm

Weight

150g (without stand)  510g with stand and box

Scanning angle

Inclination angle 45°Elevation angle 60°

Decode Capability

Auto discriminatesUPC/EAN, UPC/EAN with Supplemental

UCC/EAN 128, Code 39, Code 39 Full ASCII, Trioptic Code 39,

Code 128, Code 128 Full ASCII, Codabar, Interleaved 2 of 5,

Discrete 2 of 5, Code 93, MSI, Code 11, RSS variants, Chinese 2 of 5

Interfaces Supported

Keyboard Wedge, RS232USB

Power

Current Consumption

100mA (Idle Current < 40mA)

Voltage Requirement

5VDC ± 5%

Environment

Operating Temperature

0°C - 50°C   32°F to 122°F

Storage Temperature

-40°C - 70°C  /  -40°F to 158°F

Relative Humidity

5% - 95% (non condensing)

Shock

1.5m drop on concrete surface

Ambient Light Immunity

Immune to direct exposure of normal office

and factory lighting conditions, as well as

direct exposure to sunlight

Electrostatic Discharge

Conforms to ±15KV air discharge

and ±8KV of contact discharge

Safety

CORH class 2 laser product, FCC class B and CE







DTK3205B Bi-directional Laser Automatic Barcode ReaderDTK3205B Bi-directional Laser Automatic Barcode ReaderDTK3205B Bi-directional Laser Automatic Barcode ReaderDTK3205B Bi-directional Laser Automatic Barcode Reader
